Car transport semi trailer
15-60T car transport semi truck trailer
15-60T 3 axles vehicle carrier car transport semi trailer car transport truck trailer
Hydraulic Vehicle Carrier/Car Transport Semi Truck Trailer
Tare Weight |
15T |
dimension |
14200mm*2490mm*1575mm |
Loading Capacity |
≤60T |
Axle |
13T/16T/20T/25T,FUWA/BPW/Huajing Brand |
Rim |
8.25-20/9.00-22.5 |
Tire |
11.00R20/1200R22.5 |
Suspension |
Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW Brand) |
Spring leaf |
90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12 |
Main beam |
Main beam 500mm,up /down plate 16/18mm,webplate 10mm,side beam 16# channel steel,3 mm diamond plate |
King pin |
Jost brand 2.0 0r 3.5 inch bolts type or welding type |
Support leg |
JOST brand D200T or China brand 28Tons (Double speed) |
Main beam |
Height:500mm,upon plate is 18mm,middle plate is 10mm,down plate is 18mm;Material is Q345B Steel |
Side beam |
18”# channal steel (Material is Q235steel) |
Brake chamber |
WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber |
ABS |
Optional |
Twist Locks |
Four, Eight, Twelve pieces(Lifting type or Twist Screw Type) |
Valve |
WABCO valve |
Light |
LED light |
Voltage |
24V |
Receptacle |
7 ways(7 wire harness) |
Tool box |
One piece,1m*0.5m*0.5m(Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting |
Complete Chassis sand blasting to clean rust,1 coat of anticorrosive prime,2coats of final paint |
Shipping term |
Transport by bulk cargo carrier, RORO or 40HQ container |
Normally semi trailer is nude packing , bulk cargo , laden in bulk .
Considering our semi trailer dimension , shipping by sea .
1. OEM Service
2. Production Solutions Service
3. Customized Service
4. One-stop Shopping Service
China Heavy Duty Truck Group Sitong Special Purpose Vehicle Co.,Ltd.
Our company is sharp at manufacturing, has the leading manufacturing equipment and technology, and owns professional product inspection line and a complete CAD system,
which attributes to the winning of CCC certificate, IS09001 Quality Management Certification .
“Lufeng” is our own brand.Over the years, “Lufeng” special vehicles sell well in China and
overseas market and win great satisfaction and trust from customers.
1.Are you manufacture?
Yes. We are one of leading manufacturers for Kinds of pneumatic torque
wrench with many new production line.
2.What's your guarantee?
On the product of "Three Guarantees".
The main components of the warranty period(See table):
| ITEM NAME | WARRANTY | ITEM NAME | WARRANTY | |||
| MAIN FRAME | FRAME | 1 YEAR | RUNNING GEAR | AXLE | 6 MONTHS | |
| SUSPENSION | 6 MONTHS | AXLE BEARING | 3 MONTHS | |||
| KING PIN | 1 YEAR | WHEEL HUB | 3 MONTHS | |||
| BALANCE ARM | 3 MONTHS | TIRE | 6 MONTHS | |||
| ITEM NAME | WARRANTY | ITEM NAME | WARRANTY | |||
| BRAKING DEVICE | BRAKE DRUM | 3 MONTHS | SUPPORT DEVICE | LANDING GEAR | 6 MONTHS | |
| BRKE CHAMBER | 3 MONTHS | SPARE WHEEL CARRIER | 6 MONTHS | |||
| AIR RESERVOIR | 6 MONTHS | |||||
| ITEM NAME | WARRANTY | |||||
| OTHERS | LEAF SPRING | 3 MONTHS | ||||
| BRAKE CHAMBER DIAPHRAGM | 3 MONTHS | |||||
| EMERGENCY RELAY VALVE | 3 MONTHS | |||||
| BRAKE SHOE | 3 MONTHS | |||||
| RELAY VALVE | 3 MONTHS | |||||
3.Is OEM available?
Yes, OEM is available. We can produce our trailer according to your requirements.
And we can also put your brand on the trailer.
4.What benefits will you bring?
Your client satisfied on the quality.
Your client continued orders.
Your can get good reputation from your market and obtain more orders.
5.Technical guidance offered or not?
We could offer the use and other aspects of technical guidance according to the request of the customer.
6.Please explain more about the Package and Shipping.
There's no package but we will spary wax before shipment against saltwater corrosion.
Regarding to the shipping method, as the size of truck trailer is not small, most kinds of trailers must be delivered by Ro-ro vessel or bulk vessel. But few kinds of trailers could be delivered by container vessel. Different trailers, different shipping methods.
