Car carrier trailer car transport semi truck semi trailer
Tare Weight |
15T |
dimension |
14200mm*2490mm*1575mm |
Loading Capacity |
≤60T |
Axle |
13T/16T/20T/25T,FUWA/BPW/Huajing Brand |
Rim |
8.25-20/9.00-22.5 |
Tire |
11.00R20/1200R22.5 |
Suspension |
Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW Brand) |
Spring leaf |
90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12 |
Main beam |
Main beam 500mm,up /down plate 16/18mm,webplate 10mm,side beam 16# channel steel,3 mm diamond plate |
King pin |
Jost brand 2.0 0r 3.5 inch bolts type or welding type |
Support leg |
JOST brand D200T or China brand 28Tons (Double speed) |
Main beam |
Height:500mm,upon plate is 18mm,middle plate is 10mm,down plate is 18mm;Material is Q345B Steel |
Side beam |
18”# channal steel (Material is Q235steel) |
Brake chamber |
WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber |
ABS |
Optional |
Twist Locks |
Four, Eight, Twelve pieces(Lifting type or Twist Screw Type) |
Valve |
WABCO valve |
Light |
LED light |
Voltage |
24V |
Receptacle |
7 ways(7 wire harness) |
Tool box |
One piece,1m*0.5m*0.5m(Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting |
Complete Chassis sand blasting to clean rust,1 coat of anticorrosive prime,2coats of final paint |
Shipping term |
Transport by bulk cargo carrier, RORO or 40HQ container |
1. OEM Service
2. Production Solutions Service
3. Customized Service
4. One-stop Shopping Service
China Heavy- Duty Car Group Liangshan Sitong Special Purpose Vehicle Co., Ltd. (CNHTC)
CNHTC are one of the largest semi trailer manufacturer in China,
our factory was established in 2002, so we have been in semi trailer business line for
more than 14 years, and we are the cooperative enterprise with Sino Truck Group.
Our factory is located in Quanpu Industrial Zone, Liangshan county, Jining city,
Shandong province, China (Mainland).
We own 76, 000 square meters production base with 20,000,000
registered capital 130,000,000 fixed assets,
and our annual production capacity can reach 6,000 sets semi trailer.
In our factory, there are 750 workers, 63 technologists and four engineers.
1.Are you manufacture?
Yes. We are one of leading manufacturers for Kinds of pneumatic torque
wrench with many new production line.
2.What's your guarantee?
On the product of "Three Guarantees".
The main components of the warranty period(See table):
| ITEM NAME | WARRANTY | ITEM NAME | WARRANTY | |||
| MAIN FRAME | FRAME | 1 YEAR | RUNNING GEAR | AXLE | 6 MONTHS | |
| SUSPENSION | 6 MONTHS | AXLE BEARING | 3 MONTHS | |||
| KING PIN | 1 YEAR | WHEEL HUB | 3 MONTHS | |||
| BALANCE ARM | 3 MONTHS | TIRE | 6 MONTHS | |||
| ITEM NAME | WARRANTY | ITEM NAME | WARRANTY | |||
| BRAKING DEVICE | BRAKE DRUM | 3 MONTHS | SUPPORT DEVICE | LANDING GEAR | 6 MONTHS | |
| BRKE CHAMBER | 3 MONTHS | SPARE WHEEL CARRIER | 6 MONTHS | |||
| AIR RESERVOIR | 6 MONTHS | |||||
| ITEM NAME | WARRANTY | |||||
| OTHERS | LEAF SPRING | 3 MONTHS | ||||
| BRAKE CHAMBER DIAPHRAGM | 3 MONTHS | |||||
| EMERGENCY RELAY VALVE | 3 MONTHS | |||||
| BRAKE SHOE | 3 MONTHS | |||||
| RELAY VALVE | 3 MONTHS | |||||
3.Is OEM available?
Yes, OEM is available. We can produce our trailer according to your requirements.
And we can also put your brand on the trailer.
4.What benefits will you bring?
Your client satisfied on the quality.
Your client continued orders.
Your can get good reputation from your market and obtain more orders.
5.Technical guidance offered or not?
We could offer the use and other aspects of technical guidance according to the request of the customer.
6.Please explain more about the Package and Shipping.
There's no package but we will spary wax before shipment against saltwater corrosion.
Regarding to the shipping method, as the size of truck trailer is not small, most kinds of trailers must be delivered by Ro-ro vessel or bulk vessel. But few kinds of trailers could be delivered by container vessel. Different trailers, different shipping methods.
If you have any interests in our products, please feel free to Contact us:
MS Panny QU
Skype: pannyqu
Tel: +86 537 2882988
Mob: +86 18753778511
Email: Sitong02(at)
