YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply

Yueqing Yings Import & Export Co., Ltd.
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply thumbnail-1
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply thumbnail-2
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply thumbnail-3
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply thumbnail-4
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply photo-1
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply photo-2
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply photo-3
YUMO MS-75 5VDC 12VDC 24VDC 75W Mini Size Series SMPS LED Switch Mode Power Supply photo-4
US$ 8 - 9 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
MS-75
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number MS-75
Output Power Other, 75w
Output Type Single
Input Voltage Other, 85-264VAC
Output Voltage 5-24V
Output Frequency 47~64HZ
Output Current 3-15A



YUMO MS-75 5VDC 12VDC 24VDC 75W Mini size series SMPS LED Switch Mode Power Supply



Product Description



Specifications:
5vdc output led power supply
1 CE ROHS approved.
2. AC 85-264V Input.
3. 82% efficiency
4.2 years warranty
5vdc output led power supply
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. .2 years warrenty ,buy with confidence

General Features:



Model

Specification

MS-75-5

MS-75-12

MS-75-15

MS-75-24

DC Output voltage

5V

12V

15V

24V

Output voltage range(Note:2)

±2%

±1%

±1%

±1%

Rated output current

15A

6A

5A

3A

Output current range

0~15A

0~6A

0~5A

0~3A

Wave and noise(Note:3)

100mVp-p

75mVp-p

75mVp-p

75mVp-p

Inlet stability(Note:4)

±0.5%

±0.5%

±0.5%

±0.5%

Load stability(Note:5)

±1%

±0.5%

±0.5%

±0.5%

DC output power

75W

75W

75W

75W

Efficiency

73%

78%

78%

82%

Adjustable range for DC voltage

+10,-5%

±10%

±10%

±10%

AC input voltage range

85~132VAC/170~264VAC selected by switch 47~63Hz,240~370VDC

Input current

2A/115V 1A/230V

AC Inrush current

Cold-start current 30A/115V 60A/230V

Leakage current

<3.5mA/240VAC

Overload protection

105%-150% Type: pulsing hiccup shutdown Reset: auto recovery

Temperature coefficient

±0.03%/°C(0~50°C)

Setup, rise, hold up time

800ms, 50ms, 10ms/150V 300ms,50ms,80ms/230v

Vibration

10~500Hz, 2G 10min,/1 cycle. Period for 60min,Each axes

Withstand voltage

I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

Working temperature and humidity

-10°C~+60°C(Refer to output load derating curve),20%~90%RH

Store temperature and humidity

-20°C~+85°C,10%~95%RH

Overall dimension

111X78X36mm (L*W*H)

Weight

0.55kgS

Safety standards

UL 1012 TUV EN6050(IEC,ul1950)Approved

EMC standards

CISPR22(EN55022),IEC801-2,3,4 IEC555-2Verification
