YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply
| |||||||||
model | S-200-12 | S-200-13.5 | S-200-15 | S-200-24 | S-200-27 | S-200-48 | |||
output | Dc output voltage | 12V | 13.5V | 15V | 24V | 27V | 48V | ||
Output voltage tolerance | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | |||
Rated output current | 16.5A | 14.7A | 13A | 8.3A | 7.4A | 4.2A | |||
Output current range | 0-16.5A | 0-14.7A | 0-13A | 0-8.3A | 0-7.4A | 0-4.2A | |||
Output power | 198W | 198.45W | 198W | 199.2W | 199.8W | 201.6W | |||
Ripple and the noise | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | |||
Dc voltage adjustable scope | -16%,+10% | -12%,+11% | -10%,+20% | -16%,+10% | -4%,+18% | -15%,+17% | |||
Start, rise, keep time | 200ms,100ms,20ms Loaded with | ||||||||
input | Input voltage range | 90~132 VAC/180~264VAC 47~63 Hz;The switch choice | |||||||
Exchange input current | 4.5A/115VAC 2.5A/230VAC | ||||||||
efficiency | 76% | 79% | 78% | 82% | 82% | 83% | |||
Impulse current | 50A/115V 50A/230V | ||||||||
Leakage current | <3.5 mA/240VAC | ||||||||
Protection characteristics | Overload protection | 115%~135% | |||||||
Protection way: current limiting, automatic recovery | |||||||||
Overvoltage protection | 115%~135% | ||||||||
Protection way: voltage limitation, automatic recovery | |||||||||
High temperature protection | RTH3≥90℃when | ||||||||
environment | Working temperature, humidity | -10℃~+50℃;20%~90 %RH | |||||||
Keep temperature, humidity | -20℃~+85℃;10%~95 %RH | ||||||||
Vibrate resistance | 10~500Hz,2G 10min./1 cycle time, 60 minutes, the axis | ||||||||
security | Compression sex | Input/output: 1.5 KVAC input and between to KVAC output and the earth: 1.5:0.5 KVAC | |||||||
Insulation resistance | Between the input and output, the input and output, and ground: | ||||||||
standards | Safety standards | Accord with | |||||||
EMC standard | Drsign refer to FCC Part15 J Conduction Class A | ||||||||
other | weight | 0.93Kg | |||||||
packaging | 12pcs/11.6Kg/0.93CUFT | ||||||||
note | All the parameters in has not specified, all is in 230 VAC voltage input, rated load and 25 ℃ conditions measuring income value. Ripple and noise voltage is in 20 MHz bandwidth oscilloscope take 12 inches twisted pair end with 0.1 mu and 47 u when capacitance measurement. Tolerance is voltage setting error, the voltage adjustment rate and adjust the sum total of the current rate. Specific output current see output drop forehead curve. | ||||||||
YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply
YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-200 200W 12/24/48V Single output High efficiency power supply Switching Power Supply
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed.
4. Solved the problem with you during using our products.
5. Samples will be offered to you for our future cooperation.
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
