YUMO S-500 500W 12/24/48V Single Output High Efficiency Power Supply Switching Power Supply

Yueqing Yings Import & Export Co., Ltd.
YUMO S-500 500W 12/24/48V Single Output High Efficiency Power Supply Switching Power Supply thumbnail-1
YUMO S-500 500W 12/24/48V Single Output High Efficiency Power Supply Switching Power Supply photo-1
US$ 35 - 65 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
S-500
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number S-500
Output Power Other, 480-486W
Output Type Single
Input Voltage Other, 180-264VAC
Output Voltage 5-48V
Output Frequency 37KHz
Output Current 10-40A

YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply



Product Description

 Specifications:

1.CE RoHS approved
2.2 years warranty
3.high quality
4.83% efficiency
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence


Features:

MODEL

S-500-12

S-500-13.5

S-500-15

S-500-24

S-500-27

S-500-48

OUTPUT

DC VOLTAGE

12V

13.5V

15V

24V

27V

48V

RATED CURRENT

40A

36A

32A

20A

18A

10A

CURRENT RANGE

0 ~ 40A

0 ~ 36A

0 ~ 32A

0 ~ 20A

0 ~ 18A

0 ~ 10A

RATED POWER

480W

486W

480W

480W

486W

480W

RIPPLE & NOISE (max.)

240mVp-p

240mVp-p

240mVp-p

240mVp-p

200mVp-p

300mVp-p

VOLTAGE ADJ.RANGE

10 ~ 13.2V

12 ~ 15V

13.5 ~ 18V

20 ~ 26.4V

26 ~ 32V

41 ~ 56V

VOLTAGE TOLERANCE

±1.0%

±1.0%

±1.0%

±1.0%

±1.0%

±1.0%

LINE REGULATION

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

LOAD REGULATION

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

SETUP, RISE, HOLD TIME

200ms, 50ms, 20ms at full load

INPUT

VOLTAGE RANGE

180 ~ 264VAC (110VAC input can be custom-made)

FREQUENCY RANGE

47 ~ 63Hz

EFFICIENCY (Typ.)

84%

84%

84%

86.0%

87.0%

88%

AC CURRENT

7A/115V 3.5A/230V

INRUSH CURRENT (max.)

18A/115V 36A/230V

LEAKAGE CURRENT

<3.5mA / 240VAC

PROTECTION

OVERLOAD

105 ~ 135% of rate load

Protection type : Fold back current limiting, recovers automatically after fault condition is removed

OVER VOLTAGE

13.8 ~ 16.2V

15.5 ~ 18.2V

18 ~ 21V

27.6 ~ 32.4V

31 ~ 36.5V

57.6 ~ 67.2V

Protection type : Hiccup mode, recovers automatically after fault condition is removed.

FAN CONTROL,O.T.P.

RTH1 or RTH250ºC FAN ON,45ºC FAN, 70ºC output shut down

ENVIRONMENT

WORKING TEMP.

-10 ~ +60ºC, 20 ~ 90% RH non-condensing

WORKING HUMIDITY

20 ~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-20 ~ +85ºC, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/ºC (0 ~ 50ºC)

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS

Design refer to UL1950, TUV EN60950-1

WITHSTAND VOLTAGE

I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

ISOLATION RESISTANCE

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

EMI CONDUCTION & RADIATION

Compliance to EN55022 (CISPR22) Class B

HARMONIC CURRENT

Compliance to EN61000-3-2,-3

EMS IMMUNITY

Compliance to EN61000-4-2,3,4,5,6,8,11;ENV50204,Light industry level,criteria A

OTHERS

MTBF

138.6K hrs min. MIL-HDBK-217F (25ºC)

DIMENSION

240*125*65mm (L*W*H)

PACKING

1.35Kgs/pcs, 12pcs/17.7Kgs/0.0326CMB

  YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply

YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply

YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply





YU

Our Services

1. Reply inquiry in 24 hours.

2. Please kindly inform us which items you are interested & the reasonable price will be     provided you upon receipt of your new inquiry ASAP.

3. Answer your question detailed.

4. Solved the problem with you during using our products.

5. Samples will be offered to you for our future cooperation.

Company Information

YUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power SupplyYUMO S-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply

FAQ

Q:How to order our product ?

A:1).Please tell us the model and quantity and other request you need.

   2).We make the PI for you.

   3).After you confirm the PI, we arrange the order for you after receiving your payment.

   4).After the goods finished, we send the goods out to you and tell you the tracking number.

   5).We will track your goods until you receive the goods.

Q:  What's your warranty ?

A: One years

Q: What's your contact information:

A: Our address: Liushi town, Zhejiang province, China.    Sky-pe: benjaminying

Q: What's your shipment method?

A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.

Q: What's about MOQ?

A: First order MOQ=1pcs

Q: If i want to release order, what's the payment method you accept ?

A: We accept T/T, Paypal, Western union, L/C.

Q: If i want to release order, what's the process?

A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.

Thank you & Now pls send your  kindly inquiry !  ^!^
