Help CenterSwitching Power Supply 1200W SCN High-power Series
Related Products
-
50W Switching Power Supply NES-50-24US$ 5 - 30MOQ: 10 Pieces -
50W 24V 2.1A Switching Power Supply S-50-24US$ 5 - 50MOQ: 1 Piece
-
S-100-24 100W 24V 4.5A Switching Power SupplyUS$ 12 - 20MOQ: 10 Pieces
-
MS-50-24 Mini Size Power Supply 24VDC 2.2A 50WUS$ 5 - 50MOQ: 5 Pieces
-
RS-75-24 Power Supply 75W Single OutputUS$ 7 - 9MOQ: 10 Pieces
Specifications
switching power supply,switch power supply,DC power supplyProtection:Over load,over voltage,short circuit
Professional export
switching power supply,switch power supply,DC power supply
Protection:Over load,over voltage,short circuit
Professional export
Model |
SCN-1200-05 |
SCN-1200-12 |
SCN-1200-15 |
SCN-1200-24 |
SCN-1200-48 |
|
Output |
Direct-current output voltage |
5V |
12V |
15V |
24V |
48V |
Output voltage tolerance |
±2.5% |
±1% |
±1% |
±1% |
±1% |
|
Specified output electric current |
180A |
100A |
80A |
50A |
24A |
|
Output current scope |
0-180A |
0-100A |
0-80A |
0-50A |
0-24A |
|
Output |
900W |
1200W |
1200W |
1200W |
1200W |
|
Ripple and noise |
100mVp-p |
120mVp-p |
150mVp-p |
240mVp-p |
480mVp-p |
|
DC voltage adjustable range |
May adjust the output voltage by the exterior 1-5V voltage control to change in 20%~100% rated voltage value |
|||||
The start, the rise, maintain the time |
800ms, 50ms, 16ms full load |
|||||
Input |
Input voltage scope |
200~260 VAC47~63 Hz; 290~370VDC |
||||
Exchange input current |
11A/ 230 VAC |
|||||
Efficiency |
77% |
83% |
85% |
85% |
87% |
|
Surge current |
120A/230V |
|||||
Leaks the electric current |
3.5 mA/240VAC |
|||||
Protection feature |
Over-load protection |
101%~115% |
110%~135% |
|||
Guard mode: The current limitation, retards shuts off, starts | ||||||
Overvoltage protection |
110%~135% |
|||||
Guard mode: The cut-off output, starts | ||||||
High temperature protection |
TSW1 (power tube) temperature >100 when shuts off the output, starts |
|||||
Environment |
Operating temperature, humidity |
-10~+65,20%~90%RH |
||||
Preserved temperature, humidity |
-20~+85,10%~95%RH |
|||||
Anti-knocking property |
10~200Hz,2G 10min. /1 cycle, when long 60 minutes, various axes |
|||||
Safe |
Resistance to pressure |
I/P-O/P, I/P-FG:1500VAC |
||||
Dielectric resistance |
I/P-O/P, I/P-FG, >100M Ohms/500VDC |
|||||
Meet standards |
Standard of security |
Conforms to UL1950, CSA22.2, IEC60950 |
||||
EMC standard |
Conforms to FCC Part 15 Class A |
|||||
Other |
Weight |
4.5Kg; |
||||
Packing |
4pcs/20kg/CARTON |
|||||
Note |
1. all parameters when have not indicated specially, is in the 230VAC analog input, the rated load and 25 under the condition surveys the obtained value. 2. the ripple and the noise voltage are when the 20MHz band width oscilloscope brings 12 inch twisted pair line terminals to add 0.1μ and 47μ the electric capacity obtains. 3. the tolerance is sum total of the voltage hypothesis error, the voltage relative regulation and the electric current relative regulation. 4. this power source considered that does is a component installs on the final equipment, this equipment must confirm its EMC target. |
|||||
YUMO MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international standard IEC60898, IEC947-2
YUMO VISION:
To be an enterprise lasting 150 years and beyond
To be an enterprise with a sales network all over 200 countries in the world.
To be the cooperative partner of General Electric
YUMO MISSION:
Better product, better service.
YUMO BUSINESS PRINCIPLE
Cooperation, Sharing, Win-win
YUMO WORKING PRINCIPLE
Enjoy the work, enjoy the life.
Conditions and terms
1. All of the products are brand new, top quality components, absolutely no used items
2 .The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
Payment Terms
1.We accept payments made by Western Union, TT, PayPal, L/C
2.Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1. We will ship the items within 3-15 working days after the payment is reached.
2. We ship to you by Express, by sea, by air according to the PI.
3. Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1. Quality guaranteed for one year.
2. If the item you purchase from our company are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund.
3. If the items is defective, please notify us within 3 days of delivery.
4. Any items must be returned in their original condition to qualify for a refund or replacement.
