Help CenterMS-50-24 Mini Size Power Supply 24VDC 2.2A 50W
Related Products
-
RS-75-24 Power Supply 75W Single OutputUS$ 7 - 9MOQ: 10 Pieces -
MS-50-24 YUMO Mini Size 24VDC 2.2A 50W Power SupplyUS$ 5 - 50MOQ: 5 Pieces
-
S-50-24 YUMO 25w 24v 1a Switching Power SupplyUS$ 5 - 50MOQ: 5 Pieces
-
S-1200 Series Switching Power Supply 1200W 12VUS$ 5 - 30MOQ: 10 Pieces
-
Small Metal Case Constant Current Switching Power Supply 1200WUS$ 5 - 30MOQ: 10 Pieces
Specifications
MS-50-24 Mini size power supply 24VDC 2.2A 50W
Specification
| Model | MS-50-5 | MS-50-12 | MS-50-24 | MS-50-24 |
| Specification | ||||
| DC output voltage | 5V | 12V | 15V | 24V |
| Output voltage rang(Note:2) | +/-2% | +/-1% | +/-1% | +/-1% |
| Rated output current | 10A | 4.2A | 3.4A | 2.1A |
| Output current range | 0-10A | 0-4.2A | 0-3.4A | 0-2.1A |
| Wave and noise(Note:3) | 75mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability(Note:4) | +/-0.5% | +/-0.5% | +/-0.5% | +/-0.5% |
| Load stability(Note:5) | +/-1% | +/-0.5% | +/-0.5% | +/-0.5% |
| DC output power | 50W | 50.4W | 51W | 50.4W |
| Efficiency | 75% | 78% | 78% | 82% |
| Adjustable range for DC voltage | +10,-5% | +/-10% | +/-10% | +/-10% |
| AC input voltage range | 85~132VAC/170~264VAC selected by switch 47~63Hz;240~370VDC | |||
| Input current | 1.3A/115V 0.65A/230V | |||
| AC inrush current | Clod-start current 18A/115V 36A/230V | |||
| Leakage current | <0.5 mA/240VAC | |||
| Overload proctection | 105%~135%Type:pulsing hiccup shutdown Reset:autorecovery | |||
| Over-voltage proctection | 105%~135%Type:pulsing hiccup shutdown Reset:autorecovery | |||
| High-temperature and protection | 105%~135%Type:pulsing hiccup shutdown Reset:autorecovery | |||
| Temperature coefficient | +/-0.03(0~50) | |||
| Setup, rise,hold up time | 200ms,100ms,30ms | |||
| Vibration | 10-500Hz,,2G10min,/cycle, periodfor 60min,Each axes | |||
| Withstand voltage | Input and output interal:1.5KvAC,Input ad enclosure:1.5KvAC | |||
| Output and enclosure:0.5KvAC | ||||
| Isolation resistance | Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ | |||
| Working temperature and humidity | -10+60(Refer to output derating curve),20%90%RH | |||
| Stoerall dimension | -20+85.10%~95%RH | |||
| Overall dimension | 100*58*32mm | |||
| Weight | 0.5Kgs | |||
| Safety standards | Meet UL1012 requirement(Not apply for the mark) | |||
| EMC standaras | Meet UL1012 requirement(Not apply for the mark) | |||
| Note:1The testing condition for the paramenter aboveis:230VAC input,rated load,2570%RH | ||||
| Temperature. | ||||
| 2Error.include the setting error,line stability and load stability.(Note;5). | ||||
| 3Wavetest:adoptingA12 double wire for 20MHz,and0.1UF and 47UF capacitor short-circuit fou interrupting | ||||
| 4Inlet voltage stability test: when is over load,the lowest voltage of inlet is up to the highest voltage. | ||||
| 5Load stability test:The load is from 0%to 100% | ||||
YUMO MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international standard IEC60898, IEC947-2
YUMO VISION:
To be an enterprise lasting 150 years and beyond
To be an enterprise with a sales network all over 200 countries in the world.
To be the cooperative partner of General Electric
YUMO MISSION:
Better product, better service.
YUMO BUSINESS PRINCIPLE
Cooperation, Sharing, Win-win
YUMO WORKING PRINCIPLE
Enjoy the work, enjoy the life.
Conditions and terms
1. All of the products are brand new, top quality components, absolutely no used items
2 .The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
Payment Terms
1.We accept payments made by Western Union, TT, PayPal, L/C
2.Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1. We will ship the items within 3-15 working days after the payment is reached.
2. We ship to you by Express, by sea, by air according to the PI.
3. Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1. Quality guaranteed for one year.
2. If the item you purchase from our company are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund.
3. If the items is defective, please notify us within 3 days of delivery.
4. Any items must be returned in their original condition to qualify for a refund or replacement.
