50W 24V 2.1A Switching Power Supply S-50-24
50W 24V 2.1A Switching Power Supply S-50-2
24V 2.1A Switching Power Supply S-50-24 Specification:
| MODEL | S-50-24 | |
| OUTPUT | DC VOLTAGE | 24V |
| RATED CURRENT | 2.1A | |
| CURRENT RANGE | 0 ~ 2.1A | |
| RATED POWER | 50.4W | |
| RIPPLE & NOISE (max.) Note.2 | 100mVp-p | |
| VOLTAGE ADJ. RANGE | 22.6 ~ 26.4V | |
| VOLTAGE TOLERANCE Note.3 | ±1.0% | |
| LINE REGULATION | ±0.5% | |
| LOAD REGULATION | ±0.5% | |
| SETUP, RISE, HOLD TIME | 200ms, 100ms, 20ms at full load | |
| INPUT | VOLTAGE RANGE | 85 ~ 132VAC / 170 ~ 264VAC selected by switch 240 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz | |
| EFFICIENCY (Typ.) | 82% | |
| AC CURRENT | 1.3A/115VAC 0.65A/230VAC | |
| INRUSH CURRENT (max.) | COLD START 18A/115VAC 36A/230VAC | |
| LEAKAGE CURRENT | <1mA / 240VAC | |
| PROTECTION | OVERLOAD | 105 ~ 150% rated output power |
| Protection type: Fold back current limiting, recovers automatically after fault condition is removed. | ||
| ENVIRONMENT | WORKING TEMP. | -10 ~ +60ºC |
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing | |
| STORAGE TEMP., HUMIDITY | -20 ~ +85ºC, 10 ~ 95% RH | |
| TEMP. COEFFICIENT | ±0.03%/ºC (0 ~ 50ºC) | |
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes | |
| SAFETY & EMC | SAFETY STANDARDS | Design refer to UL1012 |
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | |
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | |
| EMI CONDUCTION & RADIATION | Design refer to FCC Part15 J Conduction Class B | |
| OTHERS | MTBF | 408.3K hrs min. MIL-HDBK-217F (25ºC) |
| DIMENSION | 159*97*38mm (L*W*H) | |
| PACKING | 0.45Kg; 30pcs/14.92Kg/0.0250CMB | |
| NOTE | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance: includes set up tolerance, line regulation and load regulation. |
|
YUMO MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international standard IEC60898, IEC947-2
YUMO VISION:
To be an enterprise lasting 150 years and beyond
To be an enterprise with a sales network all over 200 countries in the world.
To be the cooperative partner of General Electric
YUMO MISSION:
Better product, better service.
YUMO BUSINESS PRINCIPLE
Cooperation, Sharing, Win-win
YUMO WORKING PRINCIPLE
Enjoy the work, enjoy the life.
Conditions and terms
1. All of the products are brand new, top quality components, absolutely no used items
2 .The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
Payment Terms
1.We accept payments made by Western Union, TT, PayPal, L/C
2.Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1. We will ship the items within 3-15 working days after the payment is reached.
2. We ship to you by Express, by sea, by air according to the PI.
3. Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1. Quality guaranteed for one year.
2. If the item you purchase from our company are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund.
3. If the items is defective, please notify us within 3 days of delivery.
4. Any items must be returned in their original condition to qualify for a refund or replacement.
