IHU4808 2500P 48mm hollow shaft 8mm UVW singal Servo motor incremental encoder
IHU4808 2500p Servo Motor Encoder
Product Description
IHU4808 is a kind of Hollow shaft encoder, axis inside diameter 8 mm ¦, housing diameter 48 mm ¦, with flex bracket flange, easy for installing, low price at high performance.
Extensive to use for servomechanism, especially for servomotor.
1. ELECTRICAL SPECIFICATIONS
A). Output wave: Square wave
B). Output signals: A, B, Z, U, V, W, (Line driver output A, A, B, B, Z, Z, U, U, V, V, W, W phase)
C). Current consumption: d160mA
D). Response Frequency: 0~120KHz
E). Output phase difference: 90*
F). Supply voltage: 5V DC
G). Signal leve: LVHe85%Vcc, VLd0.3V
H). Number of pulses: 1000, 1024, 2048(2P, 3P, 4P); 2000(2P, 3P, 4P, 6P); 2500(2P, 3P, 4P, 5P, 6P)(Other number of pulse available on request)
I). Output circuit: Line driver
2. MECHANICAL SPECIFICATIONS
A). Speed without sealing: 6000rmp
B). Rotor moment of inertia: Appraisal 4.0x10-6Kgm2
C). Starting torque without sealing: d2.5x 10-3Nm (+25*C)
D). Shock resistance: 980m/s2, 6ms, 2 times each on XYZ
E). Vibration proof: 50m/s2, 10~200Hz, 2 hours each on XYZ
F). Working life: MTBFe50000h (+25*C, 2000rpm)
G). Weight: Appraisal 140g (with 0.35 meter cable)
3. ENVIRONMENTAL SPECIFICATIONS
A). Working humidity: 30~85% (No condensation)
B). Storage temperature: -40*C~110*C
C). Working temperature: -25*C~100*C
D). Protection class: IP54
IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder IHU4808 2500P 48mm shaft 8mm 10mm UVW singal Servo motor incremental encoder importers buyer company wholesaler retailer supplier vendor price market distributors google alibaba made in china china USA importers buyer company wholesaler retailer supplier vendor price market distributors google alibaba made in china china USA importers buyer company wholesaler retailer supplier vendor price market distributors google alibaba made in china china USA importers buyer company wholesaler retailer supplier vendor price market distributors google alibaba made in china china USA
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
