E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder
| Encoding method | Incremental |
|---|---|
| Power supply voltage | 5 VDC -5% to 5 VDC +5% (ripple (p-p): 5% Max.) |
| Current consumption | 160mA DC Max. |
| Inrush current | Current: approx. 9 A (Time: approx. 0.3 ms) |
| Resolution (Single turn type) | 500 P/R |
| Output phases | A, -A, B, -B, Z and -Z |
| Control output (Output type) | Line driver output |
| Control output (Load current) | High level(Io): -20 mA Low level(Is): 20 mA |
| Control output (Output voltage) | Vo: 2.5 V Min. Vs: 0.5 V Max. |
| Starting positional point | Equipped |
| Max. response frequency | 100 kHz |
| Phase difference on output | 90 DEG -45 to +45 DEG |
| Rise and fall times of output | Rise time of output: 0.1 us Max. Fall time of output: 0.1 us Max. (Cable length: 2m, Io: -20mA Is: 20mA) |
| Starting torque | Room temperature: 10 mN.m Max. |
| Moment of inertia | 3*10-7kg.m2 Max. |
| Shaft loading | Radial: 50 N Thrust: 30 N |
| Max. permissible rotation | 6000 r/min |
| Mechanical life expectancy | 100 million rotations Min. |
| Ambient temperature | Operating: -10 to 70 CEL Storage: -25 to 85 CEL (with no icing or condensation) |
| Ambient humidity | Operating: 35 to 85 %RH Storage: 35 to 85 %RH (with no condensation) |
| Insulation resistance | 20 M OHM Min. at 500 VDC between charged parts and the case |
| Dielectric strength | 500 VAC at 50/60 Hz for 1 minute between charged parts and the case |
| Vibration resistance | 10 to 500 Hz, 2-mm or 150m/s2 double amplitude for 11 min 3 times each in X, Y, and Z directions |
| Shock resistance | 1000m/s2 for 3 times each in X, Y, and Z directions |
| Degree of protection | IEC60529: IP64 Company standard: Oil resistance |
| Applicable standard (EC Directive (EMC Directive)) | EMI: EN50081-2 Emission Enclosure: EN55011 Group 1 classA Emission AC mains: EN55011 Group 1 classA Immunity ESD: IEC61000-4-2 Immunity RF-interference: IEC61000-4-3 Immunity Burst: IEC61000-4-4 CE marking: Equipped |
| Connection method | Pre-wired models (Cable length: 2 m) |
| Material (case) | Zinc alloy |
| Material (body) | Aluminum |
| Material (shaft) | SUS420J2 |
| Tightening torque | 0.5 N.m Max. (with M4 screw) |
| Weight (packed state) | approx. 400 g |
| Accessories | Instruction manual |
E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder E6C2-CWZ6C 720ppr 50mm Dia Shaft 8mm AB Incremental Rotary Encoder servo motor encoder der rotary encoder | usb encoder rotary encoder | e6b2 cwz6c encoder rotary encoder e6b2 | hollow shaft encoder rotary encoder | waterproof encoder rotary encoder switch | wheel encoder rotary encoder | encoder rotary encoder | encoder rotary encoder | absolute encoder rotary encoder | rotary enc IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder U4808 dc motor mini disks price Optical kit Sewing Machine encoder incremental encoder rotary encoder al encoder rotary encoder disks | 8mm encoder rotary encoder | rotary shaft encoder | encoder encoder rotary encoder | encoder rotary encoder | encoder rotary encoder disc | incremental optical encoder rotary encoders | manual encoder rotary encoder | encoder rotary encoder controler | encoder rotary encoder with switch | encoder rotary encoder circuit | hollow shaft incremental encoder rotary encoder | rotary position encoders | 12mm encoder rotary encoder | incremental encoder rotary encoders | encoder/ encoder rotary encoder | elevator encoder rotary encoder | optical encoder rotary encoders | optical encoder rotary encoder switch | absolute encoder rotary encoders | incremental 10mm encoder rotary encoder | incremental type encoder rotary encoder | incremental encoder rotary encoder | incremental optical encoder rotary encoders | hollow shaft incremental encoder rotary encoder | incremental encoder rotary encoders | incremental 10mm encoder rotary encoder | incremental type encoder rotary encoder | incremental encoder rotary encoder | incremental optical encoder rotary encoders | hollow shaft i
encoder coder haft incremental encoder rotary encoder Solid shaft
encoder rotary encoder | encoder rotary encoder price | incremental type encoder rotary encoder | encoder rotary encoder switch | incremental encoder rotary encoder | usb encoder rotary encoder | e6b2 cwz6c encoder rotary encoder e6b2 | hollow shaft encoder rotary encoder | waterproof encoder rotary encoder switch | wheel encoder rotary encoder | encoder rotary encoder | encoder rotary encoder | absolute encoder rotary encoder | rotary enc IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder U4808 dc motor mini disks price Optical kit Sewing Machine encoder incremental encoder rotary encoder al encoder rotary encoder disks | 8mm encoder rotary encoder | rotary shaft encoder | encoder encoder rotary encoder | encoder rotary encoder | encoder rotary encoder disc | incremental optical encoder rotary encoders | manual encoder rotary encoder | encoder rotary encoder controler | encoder rotary encoder with switch | encoder rotary encoder circuit | hollow shaft incremental encoder rotary encoder | rotary position encoders | 12mm encoder rotary encoder | incremental encoder rotary encoders | encoder/ encoder rotary encoder | elevator encoder rotary encoder | optical encoder rotary encoders | optical encoder rotary encoder switch | absolute encoder rotary encoders | incremental 10mm encoder rotary encoder | incremental type encoder rotary encoder | incremental encoder rotary encoder | incremental optical encoder rotary encoders | hollow shaft incremental encoder rotary encoder | incremental encoder rotary encoders | incremental 10mm encoder rotary encoder | incremental type encoder rotary encoder | incremental encoder rotary encoder | incremental optical encoder rotary encoders | hollow shaft incre
encoder coder haft incremental encoder rotary encoder Solid shaft
encoder rotary encoder | encoder rotary encoder price | incremental type encoder rotary encoder | encoder rotary encoder switch | incremental encoder rotary encoder | usb encoder rotary encoder | e6b2 cwz6c encoder rotary encoder e6b2 | hollow shaft encoder rotary encoder | waterproof encoder rotary encoder switch | wheel encoder rotary encoder | encoder rotary encoder | encoder rotary encoder | absolute encoder rotary encoder | rotary enc IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder IHU4808 8mm 48mm motor encoder Optical Sewing Machine encoder hollow shaft Incremental encoder rotary encoder U4808 dc motor mini disks price Optical kit Sewing Machine encoder incremental encoder rotary encoder al encoder rotary encoder disks | 8mm encoder rotary encoder | rotary shaft encoder | encoder encoder rotary encoder | encoder rotary encoder | encoder rotary encoder disc | incremental optical encoder rotary encoders | manual encoder rotary encoder | encoder rotary encoder controler | encoder rotary encoder with switch | encoder rotary encoder circuit | hollow shaft incremental encoder rotary encoder | rotary position encoders | 12mm encoder rotary encoder | incremental encoder rotary encoders | encoder/ encoder rotary encoder | elevator encoder rotary encoder | optical encoder rotary encoders | optical encoder rotary encoder switch | absolute encoder rotary encoders | incremental 10mm encoder rotary encoder | incremental type encoder rotary encoder | incremental encoder rotary encoder | incremental optical encoder rotary encoders | hollow shaft incremental encoder rotary encoder | incremental encoder rotary encoders | incremental 10mm enc
oder rotary encode
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
YUEQING YUMO ELECTRIC CO.,LTD
ADD: NO.126 LIUYANG ROAD ,ZHAOYANG INDUSTRY ZONE, LIUSHI TOWN,
YUEQING CITY, ZHEJIANG PROVINCE, 325604 CHINA
TEL:0086-577-62791815 Mobile:0086-13757779011
Sky-pe:benjaminying TradeManager:yncync
