YUMO PLC APB BATTERY Programmable Logic Controller
PLC --Programmable Logi
Features:
Main module: 122224 points; Extension module: 22 points; It
is flexible for extending, and the optimal configuration: 7 I/O
extension modules, 1 voice module, and 1 SMS module;
Program memory capacity: 320 FBDs, EEPROM;
It is allowed to place a Li-ion battery to power the clock;
Under the circumstance of DC12-24V, the main machine at
most has 12 voltage analog inputs 0-10V, 2 current analog inputs
0/4-20mA and 2 analog outputs 0/4-20mA;
High-speed operation: at most 4 high-speed inputs 10KHZ and
2 high-speed outputs 50KHZ;
MODBUS protocol, and can be connected to SH-300 (Text
Panel);
New function blocks: pulse width modulation (PWM), pulse
output (PTO), ACC, SMS and analog calculation etc.;
YUMO PLC Programmable Logic Controller APB BATTERY YUMO PLC Programmable Logic Controller APB BATTERY YUMO PLC Programmable Logic Controller APB BATTERY YUMO PLC Programmable Logic Controller APB BATTERY YUMO PLC Programmable Logic Controller APB BATTERY YUMO PLC Programmable Logic Controller APB BATTERY
| APB-12MRD(L) | DC12V-24V | 8 points digital input (can be used as analog inputs); I4-I7 can be high-speed ports | 4 points relay output |
| APB-12MTD(L) | DC12V-24V | 8 points digital input (can be used as analog inputs); I4-I7 can be high-speed ports | 4 points NPN transistor output |
| Q2,Q3 can be high-speed output ports | |||
| APB-12MGD(L) | DC12V-24V | 8 points digital input (can be used as analog inputs); I4-I7 can be high-speed ports | 4 points PNP transistor output |
| Q2,Q3 can be high-speed output ports | |||
| APB-22MRA(L) | AC100V-240V | 14 points input | 8 points relay output |
| APB-22MRD(L) | DC12V-24V | 14 points digital input (the first 12 points can be analog inputs); I4-I7 can be high-speed ports | 8 points relay output |
| APB-22MTD(L) | DC12V-24V | 14 points digital input (the first 12 points can be analog inputs); I4-I7 can be high-speed ports | 8 points NPN transistor output |
| Q2,Q3 can be high-speed output ports | |||
| APB-22MGD(L) | DC12V-24V | 14 points digital input (the first 12 points can be analog inputs); I4-I7 can be high-speed ports | 8 points PNP transistor output |
| Q2,Q3 can be high-speed output ports | |||
| APB-24MRDL | DC12V-24V | 2points for current input, and 14points for digital input (the first 12 points can be 0~10V analog inputs); I4-I7 can be high-speed ports | 6 points relay output + 2 analog outputs |
| APB-22ERA | AC100V-240V | 14 points digital input | 8 points relay output |
| APB-22ERD | DC12V-24V | 14 points digital input | 8 points relay output |
| APB-22ETD | DC12V-24V | 14 points digital input | 8 point NPN transistor output |
| APB-22EGD | DC12V-24V | 14 points digital input | 8 point NPN transistor output |
YUEQING YING'S IMPORT & EXPORT CO.,LTD
TEL:0086-577-62791815 Mobile:0086-13757779011
Sky-pe:benjaminying TradeManager:yncync
How to contact us:
Send your inquiry detail in the below for free samples, click "send "now.
