YUMO DR-120-24 24V 120W industrial switch power supply
- 10000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
-
New Weidmuller power supply 639B0115H02, York Kunteng control system switch power supply 639B0115H03
-
New Weidmuller Power Switching Power Supply 639B0115H01
-
ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
-
MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
-
Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
-
Power Supplies TVD1.3-15-03 Original Stock
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | YUMO power supply | Model Number: | DR-120-24 |
Output Power: | 101 - 200W | Output Type: | Single | Input Voltage: | 220V |
Output Voltage: | 12V 24V 48V | Output Frequency: | 50HZ | Output Current: | 6.5-50A |
Product Description
YUMO DR-120-24 24V 120W industrial switch power supply
Specifications
1. We have 5 Years Export Experience
2. 100% full load burn-in test
3. Approved CE, ISO 9001 certificates
4. 2 years warranty
SWITCH DIN RAIL POWER SUPPLY SINGLE TYPE DR SERIES DR-120W
1. Features
1. Globally appliance AC input power.
2. Low-cost, high reliability and
3. 105°C output capacitor
4. High efficiency, operating temperature low temperature.
5. There are short-circuit protection, overload protection.
6. Small size, light weight.
7. 100% full load burn-in test.
8. Built-in EMI filterr, a very small ripple.
9. 2 year warranty
10. DR-120-24 CE Approved 12V,24V,48V SMPS Din Rail Power Supply 12V
2. Specification
Model | Output | Tolerance Voltage | Ripple and Noise | Efficiency |
DR-120-12 | 12V, 0-10A | ± 2% | 80mvp-p | 80% |
DR-120-24 | 24V, 0-5A | ± 1% | 80mvp-p | 84% |
DR-120-48 | 48V, 0-2.5A | ± 1% | 100mvp-p | 85% |
1. Input voltage range: 88-132VAC/ 176-264VAC 47-63Hz 248-370VDC
2. Input current: 3.3A/ 115V; 2A/ 230V
3. Inrush current: cold start: 30A/ 115V, 60A/ 230V current
4. Leakage current: <3.5mA/ 240VAC
5. Temperature coefficient: 85°C±5°C (TSW1) 90°C±5°C(TSW1)
6. Start, rise, hold time: 500ms,70ms,30ms/ 230VAC
7. Earthquake resistance: 10-500Hz. 2G 10min, 1 cycle, a total of 60 minutes, each axis
8. Pressure resistance: input and output between: 3KVAC input and shell: 1.5KVAC, output and shell: 0.5KVAC
9. Isolation resistance: input and output, the input and shell, shell output: 500VDC/ 100M
10. Temperature, humidity: -10°C-+50°C, 20%-90% RH
11. Storage temperature and humidity: -20°C-+85°C, 10%-95% RH
12. Dimension (L*W*H): 65.5*125.2*100 mm
3. Please Note:
1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.
2. Error, include the setting error, line stability and load stability.
3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.
4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.
5. Load stability test: the load is from 0% to 100%, others 60%.
YUMO DR-120-24 24V 120W industrial switch power supply YUMO DR-120-24 24V 120W industrial switch power supply YUMO DR-120-24 24V 120W industrial switch power supply YUMO DR-120-24 24V 120W industrial switch power supply YUMO DR-120-24 24V 120W industrial switch power supply
