YUMO 30Watt 5VDC 12VDC -12VDC Triple Output Switching Power Supply
Specifications
1.The low price with high quality
2.CE ROHS
3.2 years quality assurance
4.LED power supply
5.small volume,high efficiency
Model | T-30B | |||
Output | DC output voltage | 5V | 12V | -12V |
Output voltage tolerance | ±1% | ±1% | ±1% | |
Rated output current | 3A | 1A | 0.5A | |
Output current | 0.5~3A | 0.1~1A | 0.1~0.5A | |
Output power | 20W | 12W | 6W | |
Ripple and noise | 50mVp-p | 100mVp-p | 50 mVp-p | |
DC adjustable range | ±10% | ±10% | ±10% | |
Setup rise hold up time | 200ms,100ms,30ms | |||
Input | Input voltage range | 85~132VAC 170~264VAC 47~63Hz 240~370VDC | ||
AC input current | 0.8A/115V 0.45A/230V | |||
Efficiency | 70% | 70% | 70% | |
AC inrush current | Cold start current 18A/115V 36A/230V | |||
Leakage current | smaller than0.75mA/240VAC | |||
Protection characteristic | Over load protection | 105%~150%rated output power start the over load protection | ||
Protection mode : cut off the output,auto-recovery | ||||
Over-voltage protection |
| |||
Environment | Working temperature | -10°C~+60°C;20%~90%RH(please refer to the Load deduction curve) | ||
Security | Withstand voltage | Between input and output::1.5KVAC The input and ground : 1.5KVAC The output and ground :0.5KVAC | ||
Insulation resistance | Between input and output: The input and ground, the output and ground: 100M 0hms /500VDC | |||
Others | Weight/Packing | 0.4kg/45PCS/19kg | ||
YUMO 30Watt 5VDC 12VDC -12VDC Triple Output Switching Power Supply YUMO 30Watt 5VDC 12VDC -12VDC Triple Output Switching Power Supply YUMO 30Watt 5VDC 12VDC -12VDC Triple Output Switching Power Supply
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
