Dual Digital Display Counter/Meter Counter/ Multifunctional Counter/H7JC2-6E2R
Description:
- H7JC2 is the upgraded version of H7JC, more functions are added:
Function:
- Recovery parameters
- Code protection
- 2 groups of relay alarm output, automatic 12VDC power supply,(for sensor use), reversible plus minus counting
- 4 grade counting speed: 30 times/sec, 300 times/sec, 2000 times/sec , 5000 times/sec
- Dimension: 72*72*90MM
- Hole size: 68*68*90MM
- Dual digital tube display: red tube shows measuring value, green one shows setting value
Parameters:
- Type: H7JC2-6E2R
- Power supply: 100-250VAC
- Input signal frequency: 0HZ-5KHZ
- Input signal: NPN signal input
- Consumption: <4W
- Output mode: 2 groups relay alram output
- Trigger capacity: AC220V,3A DC24V,5A
- Reset pulse signal: low level<=2V high level>=5V
- Input resistance:3K
- Working environment: temp 0-60 degree, humidity<=85%
- Installation: snap in
H7JC2-6E2R Modified reversible Meters Double the number with two sets of control alarm display counter H7JC2-6E2R Modified reversible Meters Double the number with two sets of control alarm display counter H7JC2-6E2R Modified reversible Meters Double the number with two sets of control alarm display counter H7JC2-6E2R Modified reversible Meters Double the number with two sets of control alarm display counter H7JC2-6E2R Modified reversible Meters Double the number with two sets of control alarm display counter Dual Digital Display Counter/Meter Counter/ Multifunctional Counter/H7JC2-6E2R
Dual Digital Display Counter/Meter Counter/ Multifunctional Counter/H7JC2-6E2R
Dual Digital Display Counter/Meter Counter/ Multifunctional Counter/H7JC2-6E
