(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump

(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump photo-1
(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump photo-2
(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump photo-3
(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump photo-4
(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump photo-5
(QBF-15 15L/m) Pump Pressure 30kPA 220V Mini Air Pump photo-6
US$ 10 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
QBF-15
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number QBF-15
Theory Vacuum Pump
Structure Single-stage Pump
Usage Other, Air Pump, Air Pump
Power Electric
Standard or Nonstandard Standard
Fuel Other, Electric
Pressure Low Pressure
Application Other, Ozone generator

QBF-15 15L/m Pump Pressure 30kPA mini air ozone generator Mini Pump







Product Description



The air output of this QBF-15 mini pump is 20~30 SCFH.


Specifications:


Air Output:



20~30 SCFH (10~15 lpm)

Pump Pressure:



4.5 PSI (30 Kpa)

Power Requirement:



220V/50Hz,120V/60Hz, AC24V available

Power Consumption:



10 W

Pump Design:



Double diaphragm, duckbill valves

Pump Body:



Aluminum?

Outlet & Inlet Dia:



0.3" (7.6 mm)

Electrical Connections:



1-ft (300 mm) Insulated wire pair

Noise Level:



40 dB unconnected, connected operation will reduce dB level.

Dimension (LxWxH):



4.2" x 3" x 2.9" (106x76x74 mm)

Net Weight:



1.4-lb (0.62 kg)


Features:
  • Compact size
  • Steady air outputs with low noise
  • Very low vibration
  • Low power consumption
  • Economical
Benefits:

Application:
  • Ozone generating system
  • Medical appliance
  • Gas sampling
