Specifications
Programmable Text Panels MT306L4.3" FSTN LCD screen smart
Programmable Text Panels MT306L
Hardware Specifications
Display screen: 4.3" FSTN LCD screen
Resolution ratio: 192 × 64 pixel (support four lines x 12 Chinese characters displayed)
LCM type: yellow-green screen / blue screen.
LCM display effect: blue screen is for blue bottom and white characters, match white light; yellow-green screen with yellow light is yellow bottom and black characters, with white light is white bottom and blue characters.
LCM life: 25±2°C,65±10% in RH conditions 50000 hours above
Brightness: 97 cd/m2
Colors: Monochrome
Contrast: adjust potentiometer
Backlight: long life of LED white or yellow light
CPU: 8-bit processor
Memorizer: 64KB Flash ROM
Formula Memory: 2KB EEPROM
Communication port: COM1: PC RS232 & PLC RS485/422 & PLC RS232
Function keys: 19 freely defined
Real Time Clock: Yes (30PPM accuracy)
Print Port: No
Allow power lost: within 20ms
General Specifications
Power supply: 12~24 VDC ±10% <150mA @ 24VDC
Immunity test: voltage 1500Vp-p, pulse period 1us, continued 1s
Dielectric Strength test: 500 V AC 1 minute
Insulation resistance: More than 10M ohms @ 500V DC
Against earthquake test: 10 ~ 25 Hz (X,Y,Z direction 2G 30 minutes)
Protection class: IP65 (front panel)
Working environment temperature: 0 ~ 50 °C
Working environment humidity: 20 ~ 90 % RH (Non-condensing)
Storage temperature: d-20°C ~ 70°C
Canning material: engineering plastics ABS
Contour dimension: 175 x 90 x 26 mm
Display dimension: 101 x 36 mm
Installation hole size: 165 x 78 mm
Cooling way: natural wind cooling
Weight: 0.3kg
Important Information about HMI Conditions
1. All of the HMI are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The HMI are guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
