Help CenterMD224L Kinco HMI Human Machine Interface
Related Products
-
YUMO SH-300-B Smart Text PanelUS$ 50 - 70MOQ: 1 Piece -
Kinco 4.3"STN Single Color HMI Text MD224L 192 X 64 20 Keys Programming Cable Software Text Panel HMIUS$ 60 - 70MOQ: 1 Piece
-
WEINVIEW HMI Touch Screen MT6070IH Plc Hmi PriceUS$ 165 - 200MOQ: 1 Piece
-
Weintek MT6070ih Touch Screen Display 7 Inch Cheap Hmi Panel HMIUS$ 165 - 200MOQ: 1 Piece
-
HMI(Human Machine Interface)4.3" TFT LCD Touch Screen MT6050iUS$ 100 - 160MOQ: 1 Piece
Specifications
MD224L Kinco HMI Human Machine Interface1.Customizable solution
2. 4.3"FSTN
3.CE and FCC pass
4.Industrial touch panel
| Model | MD224L | |
| Display | 4.3"FSTN | |
| Resolution | 192 x64 Pixel(Supporting Display of 4 Lines 12 Chinese Characters) | |
| LCM life time | Greater than 50,000 Hours at 252°C, 65±10%RH | |
| Brightness | 60 cd/m² | |
| Color | Monochromatic | |
| Contrast | Adjustable by Potentiometer | |
| Backlight | Long Service Life Yellow / Green LED | |
| CPU | 8-Bit Processor | |
| Memory | 64KB Flash ROM | |
| COM port | COM1: PC RS232 & PLC RS485/422 & PLC RS232 | |
| Real-time clock | Optional | |
| Function key | 20 Keys, Customizable(Including 12 Numeric Input Keys) | |
| Printer port | N/A | |
| Allowable power failure | Within 20ms | |
| Power supply | 12~24 VDC ±10% <150mA @ 24VDC | |
| Interference immunity test | Voltage 1500Vp-p,Pulse Cycle 1us,Duration 1s | |
| Dielectric strength | 500V AC (1 min) | |
| Isolation resistance | Exceed 10M at 500V DC | |
| Vibration endurance | 10 to 25 Hz(x, y, z Direction, 2G, 30 Minutes) | |
| Protection class | IP65 Front Panel | |
| Operating temperature | 0 ~ 50 °C | |
| Operating humidity | 20 ~ 90 % RH (Non-Condensing) | |
| Storage temperature | -20 °C ~70 °C | |
| Enclosure | Engineering Plastic ABS + PC | |
| Dimensions(W x H x D) | 172 × 95 × 30mm | |
| Display size(W x H) | 101 × 36 mm | |
| Panel cutout dimension | 165 × 86mm | |
| Cooling method | Natural Air Cooling | |
| Weight | 0.3 Kg | |
| Software | TP200 V4.7.14 or Latest | |
Important Information about HMI Conditions
1. All of the HMI are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The HMI are guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
