HMI(Human Machine Interface)MT8100I EasyView

HMI(Human Machine Interface)MT8100I EasyView thumbnail-1
HMI(Human Machine Interface)MT8100I EasyView photo-1
US$ 700 - 882.35 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
EasyView
Model Number:
MT8100i
Contact Supplier Request Quote Chat Now
Yueqing Yings Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name EasyView
Model Number MT8100i
Type TFT

Specifications

HMI,Human machine interface,touch screen,Integrated plc and
HMI (Human machine interface) MT8100i

HMI (Human machine interface) MT8100i


Display

Display:

10" TFT Widescreen

Brightness (cd/m2):

300 cd/m2

Contrast Ratio:

500:1

Color:

65536

Resolution (WXH):

800x480

Back Light:

LED

Back Light Life Time:

30,000 hr

Touch Panel

Touch Panel Type:

4 wires resistive type

Memory

Storage (RAM):

128

RAM (RAM):

64

I/O ports

SD Card Slot:

Yes

USB Host:

USB 1.1 x 1

USB Client:

USB 2.0 x 1

Ethernet Port:

10/100 Base-T

COM Port:

COM1(RS232 / RS485 2W/4W),COM2(RS232) COM3(RS232/RS485 2W)

Audio:

YES

Power

Input Power:

24 ±20% VDC

Power Consumption:

300mA@24VDC

RTC:

Built-in

Specification

Panel Cutout (WXH):

259x201mm

Weight (KG):

Approx 1.4kg

Operation

CE:

Compilies with EN 55022:2006,Class A , EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005 standards

FCC:



UL:

E248297

Voltage Resistance:

500 VAC (1 min)

Isolation Resistance:

Exceed 50MΩ at 500 VDC

Vibration Endurance:

10 to 25 Hz (X,Y,Z direction 2G 30minutes)

Protection Structure:

IP65 front panel (O ring seal)

Storage Temperature:

-20°~60°C (-4°~140°F)

Operating Temperature:

0°~50°C

Operation Humidity:

10-90% RH (non-condense)



hmi
weintek hmi

HMI(Human Machine Interface)MT8100I EasyViewHMI(Human Machine Interface)MT8100I EasyViewHMI(Human Machine Interface)MT8100I EasyViewHMI(Human Machine Interface)MT8100I EasyView



HMI(Human Machine Interface)MT8100I EasyViewHMI(Human Machine Interface)MT8100I EasyView





Important Information about HMI Conditions



1. All of the HMI are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.



Payment Terms



- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO orMTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.



Warranty



Warranty is available based on the following points:



1.The HMI are guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t   o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.
