MT4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI
Model |
MT4414T |
MT4414TE |
MT4414TE-CAN |
Performance specification | |||
Display |
7" 16:9 TFT |
||
Resolution |
800*480 |
||
Color |
65536 |
||
Backlight |
LED |
||
Brightness |
300cd/m2 |
||
Backlight life |
50000 hours |
||
Touch Panel |
4-wire precision resistance network |
||
Processor |
32-bit 400MHz RISC |
32-bit 800MHz RISC |
|
Memory |
128M FLASH + 64M SDRAM |
||
U Disk |
None |
1 USB host |
|
SD Card |
None |
||
Recipe memory & RTC |
512KB + RTC |
||
Printer port |
Serial port |
Serial port/USB port |
|
Ethernet |
None |
Support |
|
Program download |
USB SLAVE/Serial port |
USB SLAVE/Serial port/Ethernet port |
|
COM port |
COM0:RS232/RS485-2/RS485-4,COM2:RS232 |
||
Expansion Port |
None |
CANopen |
|
Software |
EV5000 V1.6 |
||
Electrical specification | |||
Rated power |
4W |
||
Rated voltage |
DC24V |
||
Input range |
12~28VDC |
||
MT4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI MT4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI MT4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI MT
YUMO MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international standard IEC60898, IEC947-2
YUMO VISION:
To be an enterprise lasting 150 years and beyond
To be an enterprise with a sales network all over 200 countries in the world.
To be the cooperative partner of General Electric
YUMO MISSION:
Better product, better service.
YUMO BUSINESS PRINCIPLE
Cooperation, Sharing, Win-win
YUMO WORKING PRINCIPLE
Enjoy the work, enjoy the life.
4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI MT4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI MT4414TE 7" 16:9 TFT LED Kinco Eview 7 cheap HMI Human machine interface PLC HMI
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
