Specifications
HMI(Human machine interface)10.4" TFT LCD touch screen MT8104iH (with Ethernet)HMI(Human machine interface)10.4" TFT LCD touch screen MT8104iH (with Ethernet)
400MHz CPU, 128MB memory;
10.4 inch TFT LCD color, 65536 800x600 resolution
The product model: MT8104iH
Product description:
400MHz CPU, 128MB memory;
10.4 inch TFT LCD color, 65536 800x600 resolution;
1 the etheric WangKou, 3 COM ports USB2.0 interface, 1, 1 USB1.1 interface
1. MT8104iH product features
10.4 "800x600
Support USB2.0 download line
TFT LCD
Support SD card using slot
LED backlighting module
Built-in power isolating protector
No fan cooling system
400MHz CPU, 128MB memory
2. MT8104iH product specifications
Monitor:
10.4 "800x600
Microprocessor:
32 Bit RISC 400MHz
Memory (DRAM) :
On board 64MB DDR2
Flash:
With 128MB flash on board
User do: 16MB bought; Log Data and to do: 48MB
Communication mouth:
Three groups of asynchronous serial communication port
COM1 (RS - 232 / RS - 485 2W / 4W)
COM2 (RS232); COM3 (RS232 / RS - 485 2W)
The etheric WangKou:
1 Ethernet port (10/100Base - T)
Audio output: Yes
USB host:
USB 1.1 clamps its x1
USB are:
USB 2.0 clamps its x1
SD slot:
have
Internal clock:
built-in
Power input:
24 + 20% VDC 300mA @ 24VDC,
WxHxD shape dimension
286 x 212 x 50
The size of holes WxH
259x201mm
Weight:
About 1.6 kg
Use the software:
EB8000 V3.4.0 or future
3. MT8104iH touch panel
Touch type:
4 line resistive
Touch mode:
successive
Completely the:
80%
Touch number
At least one million times
4. MT8104iH environmental specification
The operating temperature:
0 ° to 45 ° C (32 ° F) 113 ° -
Relative humidity:
10 ° C - 90% @ 40, no condensation
Vibration test:
10 to 25Hz (X, Y, Z direction 2gb 30 minutes)
Emi:
Comply with the FCC scale-up A
CE:
EN 2006, 55022:61000 scale-up A, EN - three -2/20 06, EN 61000-3 - yet 95 + A1:2001 + A2:2005
Waterproof:
The front panel accord with NEMA4 / IP65
5. MT8104iH LCD display
Display type:
TFT LCD
Display size (diagonal) :
10.4"
Display colors:
65,536 color
Resolution:
800 x 600
contrast
5:1
Perspective () ° :
45/65/65/65 (T/B/R/L)
Brightness (CD/m2) :
300
A backlight:
LED
A backlight life:
30,000 hours
