Home > Consumer Electronics > Display & Accessories > LCD Module > MT8150X Touch Screen Display HMI on Sales

MT8150X Touch Screen Display HMI on Sales

Name: MT8150X Touch Screen Display HMI on Sales
Brand: Weinview
SKU: 141202432
Availability: InStock

MT8150X Touch Screen Display HMI on Sales thumbnail-1

MT8150X Touch Screen Display HMI on Sales photo-1

US$ 900 - 1,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Weinview

Model Number:

MT8150X

Contact Supplier Request Quote Chat Now

Yueqing Yings Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Weinview

Model Number MT8150X

Type TFT

Specifications

HMI(Human machine interface)15" TFT LCD touch screen MT8150X

Product Description

HMI,Human machine interface,touch screen,Integrated plc and
HMI(Human machine interface)15" TFT LCD touch screen MT8150X

Features

15" TFT LCD 1024x768

32 bit CISC CPU 500 MHz
Ethernet 10/100 Base-T

Specifications

Display	15" TFT
Brightness	350 cd/m²
Color	65536 color
Contrast Ratio	550:1
Resolution(WxH)	1024x768
Back Light	CCFLx2
Touch Panel	4 wires resistive type
Touch Accuracy	2mm
Surface Hardness	4H
Serial Interface	COM1(RS232/RS485 2w/4w) COM2(RS232) COM3(RS232/RS485 2w)
Processor	32 bit CISC CPU 500 MHz
Ethernet Port	10/100 Base-T
I/O Ports	PS/2 Port Connector
USB Interface	USB 2.0 x 3, Mini USB Port x 1
Audio	Line Out x1 / MIC x 1
DRAM	256MB DDR 400MHz
IDE Interface	44 Pins IDE interface
RTC	Built-in
Input Power	24±5% VDC
Power Consumption	1A@24VDC
Panel Cutout (WxH)	352x279mm
Weight	Approx 2.9kg

Important Information about HMI Conditions

1. All of the HMI are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.

Payment Terms

- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO orMTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.

Warranty

Warranty is available based on the following points:

1.The HMI are guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.
