Help CenterMT8050i HMI Human Machine Interface, 4.3" TFT LCD Touch Screen EasyView PLC
Related Products
-
7' Touch Panel HMI Weinview TK6070IPUS$ 88 - 90MOQ: 1 Piece -
TK6070iK Weinview HMI 7 TFTUS$ 100 - 135MOQ: 1 Piece
-
TK6070iH Weinview HMI 7 TFTUS$ 100 - 135MOQ: 1 Piece
-
TK6102i Weinview HMI 10 TFTUS$ 1,700 - 1,900MOQ: 1 Piece
-
TK6102i Weinview HMI 10" TFT WidescreenUS$ 1,700 - 1,900MOQ: 1 Piece
Specifications
4.3" TFT LCD touch screen MT8050i400 MHz CPU, 128 M Flash;
4.3 inch TFT LCD color, 65536 480x272 resolution;
2 COM port, 1 (10/100Base - T) Ethernet interface
The product model: MT8050i
MT8050i product description:
400 MHz CPU, 128 M Flash;
4.3 inch TFT LCD color, 65536 480x272 resolution;
2 COM port, 1 (10/100Base - T) Ethernet interface.
1. MT8050i product features
4.3 "480x272
400MHz CPU, 64MB memory
TFT LCD adversaries
No fan cooling system
LED backlighting module
Built-in power isolating protector
2. MT8050i product specifications
Monitor:
4.3 ", Widescreen
Microprocessor:
32 Bit RISC 400MHz
Memory (DRAM) :
64 MB DDR2
Flash:
128 MB
The user program: 16 MB; Historical data capacity: 48 MB
Serial interface:
Com1: RS - 232 / RS - 485 2w / 4w 187.5 K MPI, support
Com3: RS - 485 2w
Etheric WangKou
(10/100Base - T) clamps its x1
Power input:
24 + 20% VDC 250mA @ 24VDC,
WxHxD shape dimension
128 x 102 x 38mm
The size of holes WxH
119x93mm
Weight:
About 0.3 kg
Use the software:
EB8000 V4.1.0 or future
3. MT8050i touch panel
Touch type:
4 line resistive
Touch mode:
successive
Completely the:
80%
Touch number
At least one million times
4. MT8050i environmental specification
The operating temperature:
0 ° C 32 ° to 45 ° F (C ° F) - 113
Relative humidity:
10 ° C - 90% @ 40, no condensation
Vibration test:
10 to 25Hz (X, Y, Z direction 2gb 30 minutes)
Emi:
Comply with the FCC scale-up A
CE:
EN 2006, 55022:61000 scale-up A, EN - three -2/20 06, EN 61000-3 - yet 95 + A1:2001 + A2:2005
Waterproof:
The front panel accord with NEMA4 / IP65
5. MT8050i LCD display
Display type:
TFT LCD
Display size (diagonal)
4.3"
Display colors:
65,536 color
Resolution:
480 x 272
contrast
6:1
Perspective () ° :
50/70/70/70 (T/B/R/L)
Brightness (CD/m2) :
500
A backlight:
LED
A backlight life:
30,000 hours
Important Information about HMI Conditions
1. All of the HMI are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO orMTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The HMI are guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
Contact Us:
YUEQING YING'S IMPORT & EXPORT CO.,LTD
ADD:ROOM 601,NO.126 LIUYANG ROAD,CHAOYANG VILLAGE,LIUSHI TOWN,YUEQING CITY,
ZHEJIANG PROVINCE, 325604 CHINA
TEL: 0086-577-62791815 FAX: 0086-577-62791825Mobile:0086-13757779011
Skype:benjaminying TradeManager:yncync
