Specifications
TK6102i Weinview HMI 10 TFT
Features |
|
15" TFT LCD 1024x768 32 bit CISC CPU 500 MHz |
Specifications
Display |
15" TFT |
Brightness |
350 cd/m2 |
Color |
65536 color |
Contrast Ratio |
550:1 |
Resolution(WxH) |
1024x768 |
Back Light |
CCFLx2 |
Touch Panel |
4 wires resistive type |
Touch Accuracy |
2mm |
Surface Hardness |
4H |
Serial Interface |
COM1(RS232/RS485 2w/4w) COM2(RS232) COM3(RS232/RS485 2w) |
Processor |
32 bit CISC CPU 500 MHz |
Ethernet Port |
10/100 Base-T |
I/O Ports |
PS/2 Port Connector |
USB Interface |
USB 2.0 x 3, Mini USB Port x 1 |
Audio |
Line Out x1 / MIC x 1 |
DRAM |
256MB DDR 400MHz |
IDE Interface |
44 Pins IDE interface |
RTC |
Built-in |
Input Power |
24±5% VDC |
Power Consumption |
1A@24VDC |
Panel Cutout (WxH) |
352x279mm |
Weight |
Approx 2.9kg |
General Specification
CE |
Complies with EN50081-2 and EN50082-2 standards |
FCC |
Complies with FCC Class A |
Voltage Resistance |
500 VAC (1 min) |
Isolation Resistance |
Exceed 50MΩ at 500 VDC |
Vibration Endurance |
10 to 25 Hz (X,Y,Z direction 2G 30minutes) |
Protection Structure |
IP65 front panel (O ring seal) |
Storage Temperature |
-20~60°C |
Operating Temperature |
0~45°C |
Operation Humidity |
10-90% RH (non-condense) |
Enclosure |
Aluminum |
