Product Details
Place of Origin: | Zhejiang, China | Brand Name: | EasyView | Model Number: | MT8070iH |
Type: | TFT |
Product Description
Specifications
HMI (Human machine interface)7" TFT LCD touch screen MT8070iH with ethernet port High quality
HMI (Human machine interface)7" TFT LCD touch screen MT8070iH with ethernet port
Specifications
Display | 7" TFT Widescreen |
Resolution | 800x480 |
Brightness (cd/m²) | 300 cd/m2 |
Contrast Ratio | 500:1 |
Back Light | LED |
Life Time | 30,000 hr |
Touch Panel Type | 4 wires resistive type |
Storage(MB) | 128 |
RAM(MB) | 64 |
Processor | 32 bit RISC CPU 400 MHz |
CF Card Slot | N/A |
SD Card Slot | Yes |
USB Host | USB 1.1 x 1 |
USB Client | USB 2.0 x 1 |
Ethernet Port | 10/100 Base-T |
PS2 Ports | N/A |
Mini PCI | N/A |
VGA Port | N/A |
COM Port | COM1 (RS232 / RS485 2W/4W),COM(RS232) |
Audio | N/A |
RTC | Yes |
Input Power | 24± 20% VDC |
Power Consumption | 250mA@24VDC |
Panel Cutout (mm) | 192x138mm |
Weight(Kg) | Approx 0.85kg |
Important Information about HMI Conditions
1. All of the HMI are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The HMI are guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
