Cable Gland PG7

Cable Gland PG7 thumbnail-1
Cable Gland PG7 thumbnail-2
Cable Gland PG7 thumbnail-3
Cable Gland PG7 thumbnail-4
Cable Gland PG7 thumbnail-5
Cable Gland PG7 photo-1
Cable Gland PG7 photo-2
Cable Gland PG7 photo-3
Cable Gland PG7 photo-4
Cable Gland PG7 photo-5
US$ 4 - 6 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
PG7
Contact Supplier Request Quote Chat Now
Yueqing Yings Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number PG7
Protection Level IP67
Size 4-8
Material Other, Nylon, Nylon PA66

Cable Gland PG7



Product Description

  Plastic nylon Cable Gland PG9 4-8mm






Material: A. C. E and F for UL approved Nylon PA66 (Flammability UL 94V-2), B and D for NBR rubber.
Thread: PG, M, NPT, MG
Temperature Range: -40°C to +100°C
Color: Blue, Red, Black, Yellow, Grey, White
Protection Class: IP 68
Features: The claws and seals of excellent design, can hold cable firmly and have a wider cable range. Resistant to salt water, weak acid, alcohol, oil, grease and common solvency
Type
 Remark
Divided/ Long thread MG12X1.5 5.3-3 18/15   15
  7-3.5 18/15   15
 MG16X1.5 7-4 22/22   15
  10-6 22/22   15
 MG20X1.5 8-5 24/24   15
  12-7.5 24/24   15
  10.5-6.5 27/27   15
  14-8.5 33/33   15
 MG25X1.5 16.5-11 33/33   15
 MG32X1.5 18-12.5 33/33   15
  22-16 41/41   15
  25-18 41/41   15
 MG40X1.5 32.5-24 50/50   15
 MG50X1.5 41-30 62/62   20
 MG63X1.5 54-40 75/75   20
 MG90X1.5 77-66 110/110   25
Remark
United PG PG7 3-6.5 15   8
  PG9 4-8 19   8
  PG11 5-10 22   8
  PG13.5 6-12 24   9
  PG16 10-14 27   10
  PG18 12-16 27   11
  PG21 13-18 33   11
  PG25 14-21 36   12
  PG27 15-23 38   12
  PG29 18-25 42   11
  PG36 22-32 53   13
  PG42 32-38 60   13
  PG48 37-44 65   14
  PG63 40-50 75   29
PG Flange PGF7 3-6.5 15 21 8
  PGF9 4-8 19 22 8
  PGF11 5-10 22 25 8
  PGF13.5 6-12 24 27 9
  PGF16 10-14 27 28 10
  PGF21 13-18 33 31 11
  PGF29 18-25 42 39 11
  PGF36 22-32 53 48 13
  PGF42 32-38 60 48 13
  PGF48 37-44 65 49 14
 NPT 3/8"NPT 4-8 19 26 15
  3/8"NPT 2-6 19 26 15
  1/2"NPT 6-12 24 30 13
  1/2"NPT 5-9 24 30 13
  3/4"NPT 13-18 33 37 15
  3/4"NPT 9-16 33 37 15
  1"NPT 18-25 41 40 16
  1"NPT 13-20 41 40 16
