Home > Products > Connector & Terminals > Plastic nylon Cable Gland PG9 4-8mm
Plastic nylon Cable Gland PG9 4-8mm
- 100000 Piece / Pieces per Month
- Shanghai
- Credit Card
- BNC Strain Relief Boot Black For RG59 Cable
- ev Car EMC Cable Gland IP68 EMC Elastic Clasping Cable Gland For EV Car Motor And Power
- IP68 Nickel Plated Copper Cable Gland 4 to 8mm
- High Quality Hydraulic Breather Vent Valve Big Air Flow Breather Vent Plug Black/Grey Waterproof
- Air Vent Plug Waterproof For Monitoring Systems Auto Air Vent Exhaust Valve Threaded Plug Made From Plastic Nylon
- 3/8 Inch Hydraulic Breather Vent Plug, M12*1.5 protective screw in vent and waterproof IP68 plastic
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | YUMO | Model Number: | PG9 |
Protection Level: | IP67 | Size: | 4-8 | Material: | Other, Nylon, Nylon PA66 |
Product Description
Specifications
A. C. E and F for UL approved Nylon PA66 (Flammability UL 94V- B and D for NBR rubber.Plastic nylon Cable Gland PG9 4-8mm
Plastic nylon Cable Gland PG9 4-8mm
Material: A. C. E and F for UL approved Nylon PA66 (Flammability UL 94V-2), B and D for NBR rubber.
Thread: PG, M, NPT, MG
Temperature Range: -40°C to +100°C
Color: Blue, Red, Black, Yellow, Grey, White
Protection Class: IP 68
Features: The claws and seals of excellent design, can hold cable firmly and have a wider cable range. Resistant to salt water, weak acid, alcohol, oil, grease and common solvency
Type
Remark
Divided/ Long thread MG12X1.5 5.3-3 18/15 15
7-3.5 18/15 15
MG16X1.5 7-4 22/22 15
10-6 22/22 15
MG20X1.5 8-5 24/24 15
12-7.5 24/24 15
10.5-6.5 27/27 15
14-8.5 33/33 15
MG25X1.5 16.5-11 33/33 15
MG32X1.5 18-12.5 33/33 15
22-16 41/41 15
25-18 41/41 15
MG40X1.5 32.5-24 50/50 15
MG50X1.5 41-30 62/62 20
MG63X1.5 54-40 75/75 20
MG90X1.5 77-66 110/110 25
Remark
United PG PG7 3-6.5 15 8
PG9 4-8 19 8
PG11 5-10 22 8
PG13.5 6-12 24 9
PG16 10-14 27 10
PG18 12-16 27 11
PG21 13-18 33 11
PG25 14-21 36 12
PG27 15-23 38 12
PG29 18-25 42 11
PG36 22-32 53 13
PG42 32-38 60 13
PG48 37-44 65 14
PG63 40-50 75 29
PG Flange PGF7 3-6.5 15 21 8
PGF9 4-8 19 22 8
PGF11 5-10 22 25 8
PGF13.5 6-12 24 27 9
PGF16 10-14 27 28 10
PGF21 13-18 33 31 11
PGF29 18-25 42 39 11
PGF36 22-32 53 48 13
PGF42 32-38 60 48 13
PGF48 37-44 65 49 14
NPT 3/8"NPT 4-8 19 26 15
3/8"NPT 2-6 19 26 15
1/2"NPT 6-12 24 30 13
1/2"NPT 5-9 24 30 13
3/4"NPT 13-18 33 37 15
3/4"NPT 9-16 33 37 15
1"NPT 18-25 41 40 16
1"NPT 13-20 41 40 16
Important Information about Cable GlandConditions
1. All of the Cable Glandare brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The Cable Glandguaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
