Help CenterNylon Cable Gland Waterproof Nylon Ip68 Long Thred Thread Type Cable Gland
Related Products
-
Nylon Cable Gland Nylon Nylon Cable Gland Waterproof Nylon Ip68 Pg 13.5 Thread Type Cable GlandUS$ 0.02 - 10MOQ: 10000 Pieces -
Waterproof Nylon Ip68 M22Thread Type Nylon Cable Gland Nylon Nylon Cable Gland Cable GlandUS$ 0.02 - 10MOQ: 10000 Pieces
-
Nylon Cable Gland Nylon Nylon Cable Gland Waterproof Nylon Ip68 PG 21 Thread Type Cable GlandUS$ 0.02 - 10MOQ: 10000 Pieces
-
Nylon Cable Gland Nylon Nylon Cable Gland Waterproof Nylon Ip68 M40*1.5 Thread Type Cable GlandUS$ 0.02 - 10MOQ: 10000 Pieces
-
Nylon Cable Gland Nylon Nylon Cable Gland Waterproof Nylon Ip68 PG36 Thread Type Cable GlandUS$ 0.02 - 10MOQ: 10000 Pieces
Product Overview
1. Thread: PG thread
2. Material: UL approved nylon 66(Flammability UL 94v-2)for A.C.E parts,(also accept to make super rubber, resist high temperature rubber, resist strong acid/alkali,etc)
3. Protection Degree: IP68
4. Working Temperature: -40℃ to 100℃
5. Features: The claws and seals of excellent design, sealing nut have a “click” sound and re-open, can hold cable firmly and have a wider cable range. Resistant to salt water, weak acid, alcohol, oil , grease, and common solvency.
6. Colors: Black (RAL9005), gray(RAL7.35),other color available upon request.
PG type | Product Model | Applicable to cable | Thread diameter（C1） | Thread diameter（C2） | Wrench diameter |
PG7 | 3-6.5 | 12.5 | 8 | 16 | |
PG9 | 4-8 | 15.2 | 8 | 19 | |
PG11 | 5-10 | 18.6 | 8 | 22 | |
PG13.5 | 6-12 | 20.4 | 10 | 24 | |
PG16 | 10-14 | 22.5 | 10 | 27 | |
PG19 | 12-16 | 24 | 10 | 27 | |
PG21 | 13-18 | 28.4 | 10 | 33 | |
PG25 | 16-21 | 30 | 11 | 35 | |
PG29 | 18-25 | 37 | 12 | 42 | |
PG36 | 22-32 | 47 | 14 | 52 | |
PG42 | 32-38 | 54 | 14 | 60 | |
PG48 | 37-44 | 59.3 | 15 | 64 | |
PG63 | 42-50 | 71 | 28 | 77 |
