IEC Standard CE Certified High Efficiency Three Phase Electric Motor

IEC Standard CE Certified High Efficiency Three Phase Electric Motor thumbnail-1
IEC Standard CE Certified High Efficiency Three Phase Electric Motor photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
HALOTOP
Model Number:
160L
Type:
Asynchronous Motor
Contact Supplier Request Quote Chat Now
Shanghai Halotop Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Sea Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HALOTOP
Model Number 160L
Type Asynchronous Motor
Frequency 50hz
Output Power 18.5-90KW
Protect Feature Totally Enclosed
Phase Three-phase
Certification CE, UL
AC Voltage Other, 220--660v
Place of Origin Shanghai, China
Efficiency IE 2

Specifications

1.IEC standard High efficiency Three phase electric motor
2.CE Certified
3.Cast Iron Motor
4. Power:18.5-90kw

  IEC Standard CE Certified High efficiency Three Phase Electric Motor





Features
1.Energy saving, high efficiency
2.High starting torqaue,lower starting current
3.Versatile design(easy to modify for varieties of application
4.Option of integrated or removable foot
5.Option of aluminum housing up to frame size 200
6.Option of terminal box location(top, left or right)

Applications
1.Pumps
2.Waste water treatment plant
3.Air compressors, fans
4.Gear reducers and power transmission
5.Pulp and paper mill
6.Steel mill
7.Conveyors, elevators
8.Should be "Material handling equipments"
9.Agricultural applications
10.Mining equipment
11.Hydraulic equipments





Model Power
(KW)		 Full Load Speed
(r/min)		 Inl400V
(A)
 		Ifl400V
(A)
 		Ist/In
(Times) 		Eff.
100%FL
(%)		 Power Factor
(Cosφ)		 Full Load Torque
(N.M)		 Tst/Tn
(Times) 		Tmin/Tn
(Times) 		Tmax/Tn
(Times)
160L-2 18.5 2922 9.64 31.93 8 90.9 0.92 60.46 2.4 2.1 2.9
180M-2 22 2930 13.6 39.08 7.5 91.3 0.89 71.7 2.3 2 2.8
200L1-2 30 2925 19.39 53.49 6.7 92 0.88 97.94 2.4 2 2.7
200L2-2 37 2930 21.36 64.15 6.3 92.5 0.9 120.59 2.3 2 2.7
225M-2 45 2930 28.81 79.45 6.9 92.9 0.88 146.66 2.3 2 2.8
250M-2 55 2940 35.09 96.8 8 93.2 0.88 178.64 2.3 1.9 2.7
280S-2 75 2940 37.86 125.45 8 93.8 0.92 243.6 2.2 1.9 2.7
280M-2 90 2940 45.28 150.06 7.7 94.1 0.92 292.33 2.2 1.9 2.6

  IEC Standard CE Certified High efficiency Three Phase Electric MotorIEC Standard CE Certified High efficiency Three Phase Electric Motor

  IEC Standard CE Certified High efficiency Three Phase Electric Motor IEC Standard CE Certified High efficiency Three Phase Electric Motor
