58HP fire fighting diesel engine with radiator 490

Name: 58HP fire fighting diesel engine with radiator 490
Brand: HALOTOP
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Product Details

Condition:	New	Usage:	Other, Fire fighting diesel engine and system	Fuel:	Diesel
Stroke:	4 Stroke	Cylinder:	Multi-cylinder	Cold Style:	Other, Water-cooled
Start:	Electric Start	Place of Origin:	Jiangsu, China	Brand Name:	HALOTOP
Model Number:	490	Dimension(LWH):	113X68X97 cm	Weight:	360KGS
Warranty:	One year near our servise station in Dubai	After-sales Service Provided:	Overseas service center available

58HP fire fighting diesel engine with radiator 490
with radiator, air fliter,muffler,solenoid valve.

58HP fire fighting diesel engine with radiator 490

diesel engine 58HP / 490 fire fighting equipment / fire fighting diesel engine

Product Description

RADIATOR SERIES FIRE FIGHTING EQUIPMENT
Engine Model		380	480	485	490	4100
Type		Vertical,water-cooling 4-stroke,direct-injector
Aspiration		Nature
Number of Cylinders		4	4	4	4	4
Bore*Storke(mm)		80*90	85*90	85*95	90*105	100*118
Compression Ratio		18:01	18:01	18:01	18:01	18:01
Total Displacement(L)		1.357	1.809	2.156	2.67	3.705
Rated Power	KW/HP	20/27	27.8/37	22.5/45	42/58	56/75
Rated Speed	r/min	3000	3000	3000	3000	3000
Max.torque	N.m	≥72.6	99.8	≥118.2	≥149.7	≥193
Fuel Consumption	g/kW.h	≤242	≤241	≤241	≤258	≤238
Radiator		RD480	RD480	RD485	RD490	RD4100
Rotating Direction at Output End		Counter-clockwise
Lubrication Oil		15W40
Lubrication Oil Content	L	4.5	6	6.5	7	9
Lubrication Method		Pressure and splash
Starting Method		Electric
PTO Type		Option:1.Shaft2.Coupling3.Drive Plate
Net Mass	kg	250	300	320	360	420
