Fire Fighting Training Equipment With Turbocharger 4105T
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HALOTOP
Model Number:
4105T
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Fire Fighting Equipment With Shaft 4100 Diesel EngineNegotiableMOQ: 1 Set -
New Fire Fighting Equipment With 6 Cylinders Diesel Engine 6102BZSNegotiableMOQ: 1 Set
-
Fire Fighting Training Equipment With Heat Exchanger 485NegotiableMOQ: 1 Set
-
Fire Fighting Equipment Diesel Engine With Heat Exchanger 490NegotiableMOQ: 1 Set
-
Fire Fighting Equipment With Heat Exchanger 4102NegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HALOTOP
Model Number
4105T
Specifications
Fire fighting training equipmentwith shaft, radiator, air fliter,muffler,solenoid valve.
Product Description
Fire fighting equipment with turbocharger 4105T
Fire fighting equipment / diesel engine / fire fighting training equipment
| Engine Model | 380 | 480 | 4100 | 4105T | 6102BZS | |
| Type | Vertical,water-cooling 4-stroke,direct-injector | |||||
| Aspiration | Nature | Turbo-charged | ||||
| Number of Cylinders | 4 | 4 | 4 | 4 | 6 | |
| Bore*Storke(mm) | 80*90 | 85*90 | 100*118 | 105*118 | 102*118 | |
| Compression Ratio | 18:01 | 18:01 | 18:01 | 17.5:1 | 17:01 | |
| Total Displacement(L) | 1.357 | 1.809 | 3.705 | 4.085 | 5.78 | |
| Rated Power | KW/HP | 20/27 | 27.8/37 | 56/75 | 90/122 | 125/170 |
| Rated Speed | r/min | 3000 | 3000 | 3000 | 3000 | 3000 |
| Max.torque | N.m | ≥72.6 | 99.8 | ≥193 | ≥315 | ≥438 |
| Fuel Consumption | g/kW.h | ≤242 | ≤241 | ≤238 | ≤238 | ≤205 |
| Radiator | RD480 | RD480 | RD4100 | RD4105T | RD6102 | |
| Rotating Direction at Output End | Counter-clockwise | |||||
| Lubrication Oil | 15W40 | |||||
| Lubrication Oil Content | L | 4.5 | 6 | 9 | 11 | 13 |
| Lubrication Method | Pressure and splash | |||||
| Starting Method | Electric | |||||
| PTO Type | Option:1.Shaft2.Coupling3.Drive Plate | |||||
| Net Mass | kg | 250 | 300 | 420 | 500 | 720 |
