Home > Industrial Equipment & Components > Engine & Part > Engine > New Fire Fighting Equipment With 6 Cylinders Diesel Engine 6102BZS
New Fire Fighting Equipment With 6 Cylinders Diesel Engine 6102BZS
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Fire fighting diesel engine and system
Fuel:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fire Fighting Training Equipment With Heat Exchanger 485NegotiableMOQ: 1 Set -
Fire Fighting Equipment Diesel Engine With Heat Exchanger 490NegotiableMOQ: 1 Set
-
Fire Fighting Equipment With Heat Exchanger 4102NegotiableMOQ: 1 Set
-
Fire Fighting Training Equipment With Heat Exchanger 380NegotiableMOQ: 1 Set
-
Fire Fighting Training Equipment With Heat Exchanger 485NegotiableMOQ: 1 Set
Condition
New
Usage
Other, Fire fighting diesel engine and system
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Multi-cylinder
Cold Style
Other, Water-cooled
Start
Electric Start
Place of Origin
Jiangsu, China
Brand Name
HALOTOP
Model Number
6102BZS
Dimension(L*W*H)
150X93X135 mm
Weight
720 KGS
Warranty
One year near our servise station in Dubai
After-sales Service Provided
Overseas service center available
Specifications
New fire fighting equipment with 6 cylinders 6102BZSwith shaft, radiator, air fliter,muffler,solenoid valve.
Product Description
New fire fighting equipment with 120L fuel tank diesel engine 6102BZS
New fire fighting equipment / diesel engine / fire fighting equipment
| Engine Model | 380 | 480 | 4100 | 4105T | 6102BZS | |
| Type | Vertical,water-cooling 4-stroke,direct-injector | |||||
| Aspiration | Nature | Turbo-charged | ||||
| Number of Cylinders | 4 | 4 | 4 | 4 | 6 | |
| Bore*Storke(mm) | 80*90 | 85*90 | 100*118 | 105*118 | 102*118 | |
| Compression Ratio | 18:01 | 18:01 | 18:01 | 17.5:1 | 17:01 | |
| Total Displacement(L) | 1.357 | 1.809 | 3.705 | 4.085 | 5.78 | |
| Rated Power | KW/HP | 20/27 | 27.8/37 | 56/75 | 90/122 | 125/170 |
| Rated Speed | r/min | 3000 | 3000 | 3000 | 3000 | 3000 |
| Max.torque | N.m | ≥72.6 | 99.8 | ≥193 | ≥315 | ≥438 |
| Fuel Consumption | g/kW.h | ≤242 | ≤241 | ≤238 | ≤238 | ≤205 |
| Radiator | RD480 | RD480 | RD4100 | RD4105T | RD6102 | |
| Rotating Direction at Output End | Counter-clockwise | |||||
| Lubrication Oil | 15W40 | |||||
| Lubrication Oil Content | L | 4.5 | 6 | 9 | 11 | 13 |
| Lubrication Method | Pressure and splash | |||||
| Starting Method | Electric | |||||
| PTO Type | Option:1.Shaft2.Coupling3.Drive Plate | |||||
| Net Mass | kg | 250 | 300 | 420 | 500 | 720 |
