3g Modem Rs232 and USB Interface WCDMA/GSM/GPRS/EDGE Module Solution

RS232+USB 3G/HSDPA MODEM

1.Driver hsdpa usb modem

2.Simcom module SIM5216E

3.WCDMA/HSDPA: 900/2100MHZ

4.GSM/GPRS/EDGE: 850/900/1800MHZ

Product description

General features

Industrial design

Aluminum casing

RS232+USB interface

Based on Simcom module SIM5216E

With TCP/IP stack

WCDMA/HSDPA 900/2100MHZ

GSM/GPRS/EDGE:850/900/1800MHZ

GPRS class 12

EDGE class 12

UMTS/HSDPA 3GPP release 5

GSM 3GPP release 99

LED for signal

SIM application toolkit

3V SIM card slot

Internet, data and SMS service

Output Power
               - Class 4(2W @ 850/ 900MHz GSM)
               -Class 1(1W @ 1800MHz GSM)

               -Class 3 (0.25W @ 900/2100MHZ)
Input voltage 7.5V-30V DC
Input current 1A-2A

Standby current: 56mA

Working current: 100-140mA
Working temperature: -30 to +80 degrees

Storage temperature:-40 to +85 degrees

Size 85*54*25mm
Weight 100g

Accessories: AC/DC adaptor, DB9 RS232 cable, USB cable, antenna, 2 mounting plates, CD

Spec for Data:

HSDPA: Max. 3.6 mbps (DL)

WCDMA: Max. 384 Kbps (DL), Max.384Kbps (UL)

EDGE: Max. 236. 8 Kbps (DL),Max118 Kbps (UL)

GPRS: Max. 85.6 Kbps (DL), Max.42.8 Kbps (UL)

CSD: 2.4/4.8/9.6/ 14.4kbps,

     Non-transparent mode

GPRS coding scheme: CS 1-4

EDGE coding scheme: MCS 1-9

PAP,PPP, PBCCH USSD

UMTS R99

Spec for SMS

MO, MT,CB

SMS Cell broadcast

Text and PDU mode
