LD (L) series agricultural film blowing machine plant
- 4 Set / Sets per Month
- Qingdao
- T/T
- High speed Plastic bottle making 0.5L- 2L 6000BPH Automatic PET bottle blow blowing mold molding machine prices
- Factory Price High Quality Automatic Fast Plastic PP HDPE Bottle Blowiing Jerrycan Extrusion Blow Molding Machine
- Semi Automatic PET Plastic Bottle 5 Gallon 20 Liter Blow Molding Machine Price
- custom design semi-automatic preform pet plastic bottle blowing blow molding machine high speed
- Semi-automatic Two Cavity Bottle Making Machine Blow Molding Equipment
- Plastic bottle blowing machine Beverage bottle blowing machine Medicine bottle blowing machine
Product Details
Condition: | New | Application: | Film | Plastic Processed: | PE |
Blow Moulding Type: | Extrusion Blow Moulding | Automatic: | No | Place of Origin: | Shandong, China |
Brand Name: | Hengxiang | Model Number: | LD1100/LD1300/LD1600/LD2200/LD2500/LD2650/LD2800 | Warranty: | 12 months |
After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
1. Applicable for producing agricultural film of LDPE, LLDPE, and LLDPE/LDPE blend.2. Good yield and long service life.
1. Thickness: 0.003-0.009mm .04-0.08mm
Structural characteristics:
- LD (L) series agricultural film blowing machine is applicable for producing agricultural film (0.003-0.009mm .04-0.08mm) of LDPE, LLDPE, and LLDPE/LDPE blend.
- The die adopts advanced central head feeding spiral runner molding technology.
- Molding and cooling of the film adopts air blower and air ring with high-property, low air pressure, and large air volume.
- The extruder adopts corrugated screw with oblique barrier and mixing head, which assures stable and reliable performance, high output and low energy consumption.
- It adopts friction type double surface wind-up, which has improved the flatness of the film, and made the coiling structure tight. It is easier to operate. A length metering device is installed, which makes the length of the film accuracy.
- The electrical components are domestic famous brand.
Main technical parameters:
Model | LD1100 | LD1300 | LD1600 | LD2200 | LD2500 | LD2650 | LD2800 |
Max. folding width of ground film | 1,000 | 1,200 | 1,500 | 2,000 | 2,300 | 2,500 | 2,600 |
Max. folding width of farm film | 800 | 1,000 | 1,300 | 1,800 | 2,100 | 2,300 | 2,400 |
Ground film thickness | 0.003-0.009 | ||||||
Farm film thickness | 0.04-0.08 | ||||||
Outputs kg/h | 50 | 52 | 110 | 130 | 180 | 220 | 240 |
Applicable material | LDPE, LLDPE, LDPE/LLDPE Blend | ||||||
Screw diameter | 45 | 50 | 65 | 75 | 75 | 90 | 90 |
L/D of screw | 30 | 28 | 28 | 28 | 30 | 30 | 30 |
Max. rotating speed of screw | 130 | 130 | 140 | 105 | 110 | 120 | 120 |
Type of the main motor | Can be matched by the requirements of the customer | ||||||
Power of main motor | 15 | 18.5 | 37 | 45 | 55 | 75 | 90 |
Die head type | Spiral die head | ||||||
Highest speed for ground film coiling | 120 | 120 | 120 | 120 | 100 | 80 | 80 |
Highest speed for farm film coiling | 30 | ||||||
Total power | 28 | 32.5 | 72 | 80 | 88 | 105 | 180 |
Size | 6.2×2.3×5 | 6.4×2.5×5 | 6.6×3×6.8 | 7.5×2.5×7.7 | 7.8×3.2×10.5 | 8×3.5×10.5 | 13×4×9 |
Weight | 5.2 | 5.5 | 6.5 | 8.5 | 16 | 19.5 | 21 |
