Specifications
1. Double-layer Water Delivery Belt Production Line2. water cooling
3. different sizes
4. line speed: 8-80m/min
If customer requires our technician to install in the customer’s factory, the expenses for one of supplier's technicians going to the country of customer to install equipment and train staffs, including fees of round-trip air ticket, accommodation, as well as service charge, and so on, will be afforded by buyer. Service charge will be USD80 per day.
1.The supplier provide all the machinery and equipment can meet the requirements of agreement and the corresponding standards.
2. Main parts warranty for one year, unit electric parts warranty half a year.
3.The supplier should be 12 months after shipment in equipment, material and process of design defects caused by any free on the damage to the machinery and equipment repair.
4.The supplier would be irresponsible for error handing, assembly, tighting and operation caused by damage.
Specifications of the products:
Φ110, Φ120, Φ145, Φ150, Φ180, Φ200, Φ220
Applications of the products:
It is widely used for the irrigation of farmland, garden and greenhouse planting to replace the original common hose.
Properties of the products:
The double-layer bottom blowing water delivery belt uses bottom blowing method with two extruders to co-extrude. It adopts labyrinth water immersion to cool for molding, which strengthens the burst strength and pressure of the water delivery belt. The physical strength is three times of the common water hose (water delivery belt.
Mechanical characteristics of the double-layer bottom blowing water delivery belt:
- it adopts two extruders with equivalent models sharing the same double-layer die head. It uses different raw materials to co-extrude and adopts frequency conversion timing control.
- The water delivery belt machine set and the water delivery belt molding adopt the labyrinth water immersion type vacuum molding device.
- It adopts the parallel crawler haling and frequency conversion device.
- The coiling of the water delivery belt machine set uses double-stage central rolling-up and torque tension control.
- The electric control uses the intelligent digital subdivision control.
Main technical parameters
Extruder model | SJ-55*2 | SJ-50*2 |
Screw dia./L:D | Φ55/30:1 | Φ50/30:1 |
Motor power kw | 22*2 | 18.5*2 |
Specifications of the die head mm | Φ110, Φ120, Φ145, Φ150, Φ180, Φ220 (selected by users) | |
Cooling method | Water cooling | |
Sizing sleeve | Matched with the die head (Φ110-Φ220) with the material of tin bronze | |
Specifications of the vacuum pump kw | 2.2 | 1.5 |
Haul-off motor kw | 2.2 (frequency control) | 1.5 (frequency control) |
Roll-up style | Double-position central wind-up | |
Speed of the production line | 8-80 m/min | |
The parameters above can be changed without notice.
