Price Diesel Generator 15kva-500kva Weichai Ricardo

Name: Price Diesel Generator 15kva-500kva Weichai Ricardo
Brand: Ricardo
SKU: 141184886
Availability: InStock

Weifang Huatian Diesel Engine Co., Ltd.

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Ricardo

Model Number:

15kva

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Ricardo

Model Number 15kva

Output Type AC Three Phase

Speed 1500/1800 r/min

Frequency 50/60hz

Rated Power 12KW

Rated Voltage 400/380V

Rated Current 27A

Price Diesel Generator 15kva-500kva Weichai Ricardo

Product Description

Technical data
Genset Model	20GF
Genset Output Power	20KW
Rated Voltage	380/220V
Frequency	50Hz
Power Factor(COS)	0.8(lagging)
Dimension (L×W×H) (mm)	1730×790×1310
Net weight (kg)	600
Diesel Engine
Brand	Weifang Huatian
Model	K4100D
Engine Structure	In line 4 cylinder, 4 stroke, turbocharged
Rotating Speed	1500r/min
Engine Cooling Method	Water-cooled
Governor System	Mechanical governor system
Aspiration mode	Nat/asp
Starting Method	12V DC electric starting
Displacement(L)	3.61
Bore×Stroke(mm)	100×115
100% load fuel consumption (g/kwh)	248
Alternator
Brand	Chinese Stamford
Excite Type	Brushless ,Self-exciting, AVR automatic voltage regulating
Connecting Type	3 Phase and 4 Wires
Steady Frequency Change	05%
No load voltage	≥95%105%
Steady voltage	≤±1%
Insulation degree	H degree
Enclosure degree	IP21
The components of the genset
(1) Diesel engine; (2) Generator; (3) Control panel
