500KW WEIFANG Diesel Generator With KTAA19-G6 Engine
Product Description
| Technical Specifications | ||
|---|---|---|
| Diesel Generator Set | Model No. | HT500GF |
| Rated Output(KW/KVA) | 500/625 | |
| Standby Output(KW/KVA) | 550/687.5 | |
| Size(MM) | 3600*1550*2230 | |
| Weight(KG) | 5000 | |
| Diesel Engine | Model No. | KTAA19-G6 |
| Engine Characters | Direct-injection, water-cooling, four stroke,in line | |
| Rated Output(KW/KVA) | 520/1650 | |
| Standby Output(KW/KVA) | 570/713 | |
| Cylinder NO. | 12 | |
| Aspiration | Turbocharged | |
| Bore(MM)*Stroke(MM) | 159/159 | |
| Compression Ratio | 13.5:1 | |
| Displacement(L) | 18.9 | |
| Start Type | DC 24V electric start | |
| Rated Speed(RPM) | 1500 | |
| Rated Fuel Consumption(G/KW.H) | ≤206 | |
| Alternator | Model No. | TZH-500 |
| Continuous Output(KW/KVA) | 500/625 | |
| Voltage Control | AVR | |
| Excitation Type | Brush/Brussless | |
| Insulation Class | H | |
| Brand | Stanford/Stanford copy | |
| Voltage(V) | 230/400 | |
| Current(A) | 900 | |
| Frequency(HZ) | 50HZ | |
| Power Factor | 0.8 | |
| Phase | 3 phases, 4 wires | |
