350KW WEIFANG Diesel Generator With NTAA855-G7A Engine

Name: 350KW WEIFANG Diesel Generator With NTAA855-G7A Engine
Brand: Weichai Huatian
SKU: 141184372

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Weichai Huatian

Model Number:

HT350GF

Weifang Huatian Diesel Engine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Weichai Huatian

Model Number HT350GF

Output Type AC Three Phase

Speed 1500rpm

Frequency 50Hz

Rated Power 350kw

Rated Voltage 220/400V

Rated Current 630A

350KW WEIFANG Diesel Generator With NTAA855-G7A Engine

Product Description

Technical Specifications
Diesel Generator Set	Model No.	HT350GF
	Rated Output(KW/KVA)	350/437.5
	Standby Output(KW/KVA)	385/481
	Size(MM)	350012001900
	Weight(KG)	5200
Diesel Engine	Model No.	NTAA855-G7A
	Engine Characters	Direct injection, water-cooling, four- stroke, in line,
	Rated Output(KW/KVA)	370/463
	Standby Output(KW/KVA)	407/509
	Cylinder NO.	6
	Aspiration	Turbocharged
	Bore(MM)*Stroke(MM)	159*159
	Compression Ratio	14.5:1
	Displacement(L)	11
	Start Type	DC 24V electric start
	Rated Speed(RPM)	1500
	Rated Fuel Consumption(G/KW.H)	≤ 203
Alternator	Model No.	TZH350
	Continuous Output(KW/KVA)	350/438
	Voltage Control	AVR
	Excitation Type	Brush/ Brushless
	Insulation Class	H
	Brand	Stanford/Stanford copy
	Voltage(V)	230/400
	Current(A)	630
	Frequency(HZ)	50HZ
	Power Factor	0.8
	Phase	3-phases,4-wires
