Specifications
1)China Generator2)50/60hz, 3phase and 1 phase
3)2years warranty
4)Rated Power:24kw/30kva
5)Lifetime Service
1,China Generator Set Specification,
GENSET MODEL | 24GF | |
PRIME | STANDBY | |
GENSET OUTPUT | 24KW | 26.4kw |
GENSET OUTPUT | 30KVA | 33KVA |
SHORT CIRCUIT PROTECTION | MCCB | |
VOLTAGE/FREQUENCY/POWER FACTOR | 400V,50Hz,0.8lag, 3 Phase and 4 Wires | |
RELATIVE VOLTAGE ADJUST RANGE | 0~5% | |
MOMENT VOLTAGE ADJUST RATIO | -15%~+20% | |
STEADY FREQUENCY ADJUST RATIO | 0~5% | |
MOMENT FREQUENCY ADJUST RATIO | 3% | |
TIME OF STEADY VOLTAGE | ≤ 4s | |
TIME OF STEADY FREQUENCY | ≤ 3s | |
WINDAGE OF STEADY VOLTAGE | ≤ ±1% | |
FREQUENCY FLUCTUATION RATIO | 0.5% | |
DIESEL ENGINE MODEL | RICARDO-K4100D | |
ENGINE OUTPUT (KW) | 30kw | |
ENGINE CONFIGURATION | In-Line,Water Cooling,Four -Stroke | |
ASPIRATION | Naturally Aspirated | |
DISPLACEMENT(L) | 4 | |
SPEEDING (R/MIN) | 1500 | |
START MODEL | ELECTRIC MOTOR START | |
SPEED GOVERNOR | Mechanical | |
FUEL CONSUMPTION G/KW.H) | 224 | |
ALTERNATOR | STAMFORD | |
ALTERNATOR MODEL | 184G | |
TYPE | 3 PHASE AND 4 WIRES,BRUSHLESS EXCITATION,SELF-RADIATOR,SELF REGULATING VOLTAGE | |
INSULATION CLASS | H | |
APPRXOMATE DIMENSION(MM) | 1900*750*1450 | |
Net Weight(KG) | 900 | |
2, Other optional configuration,
Any colour.
Urgent Condition Protection Panel.
AMF and ATS.
Silent/Soundproof Canopy.
3,Commercial Term,
Warranty: 2 Years.
Payment: T/T or L/C.
Delivery:15days.
Minimum Order Quanty:1 Piece.
|
|
