Steyr 200kw/250kva Diesel Generator With Control Panel

Name: Steyr 200kw/250kva Diesel Generator With Control Panel
Brand: Ricardo
SKU: 141184248
Availability: InStock

Weifang Huatian Diesel Engine Co., Ltd.

US$ 10,000 - 11,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Ricardo

Model Number:

200GF

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Ricardo

Model Number 200GF

Output Type AC Three Phase

Speed 1500/1800rpm

Frequency 50/60hz

Rated Power 200kw/250kva

Rated Voltage 400/230v

Rated Current 360A

Specifications

1)Diesel Generator
2)50/60hz, 3phase and 1 phase
3)2years warranty
4)Rated Power:200kw/250kva
5)Lifetime Service

1,200kw Diesel Generator Specification,

GENSET MODEL	200GF
	PRIME	STANDBY
GENSET OUTPUT	200KW	220kw
GENSET OUTPUT	250KVA	275KVA
SHORT CIRCUIT PROTECTION	MCCB
VOLTAGE/FREQUENCY/POWER FACTOR	400V,50Hz,0.8lag, 3 Phase and 4 Wires
RELATIVE VOLTAGE ADJUST RANGE	0~5%
MOMENT VOLTAGE ADJUST RATIO	-15%~+20%
STEADY FREQUENCY ADJUST RATIO	0~5%
MOMENT FREQUENCY ADJUST RATIO	3%
TIME OF STEADY VOLTAGE	≤ 4s
TIME OF STEADY FREQUENCY	≤ 3s
WINDAGE OF STEADY VOLTAGE	≤ ±1%
FREQUENCY FLUCTUATION RATIO	0.5%
DIESEL ENGINE MODEL	Steyr-6126ZLD
ENGINE OUTPUT (KW)	240kw
ENGINE CONFIGURATION	In-Line,Water Cooling,Four -Stroke
ASPIRATION	Turbocharged
DISPLACEMENT(L)	6
SPEEDING (R/MIN)	1500
START MODEL	ELECTRIC MOTOR START
SPEED GOVERNOR	Mechanical
FUEL CONSUMPTION G/KW.H)	224
ALTERNATOR	STAMFORD
ALTERNATOR MODEL	274K
TYPE	3 PHASE AND 4 WIRES,BRUSHLESS EXCITATION,SELF-RADIATOR,SELF REGULATING VOLTAGE
INSULATION CLASS	H
APPRXOMATE DIMENSION(MM)	300010001800
Net Weight(KG)	2800
