noncorrosive submersible agitator slurry pump
SP SPR noncorrosive submersible agitator slurry pump PERFORMANCE PARAMETERS
| Model | Power | Material | Performance | Impeller | ||||||
| Volute | Impeller | Flow |
Head (m) |
Speed |
Efficiency (%) |
No.of vane |
Dia.of Impeller |
|||
| m3/h | L/S | |||||||||
| 40PV | 15 | M | M | 19.44-43.2 | 5.4-12 | 4.5-28.5 | 1000-2200 | 40 | 5 | 188 |
| 40PV | RU | RU | 17.28-39.6 | 4.8-11 | 4-26 | 1000-2200 | 40 | 5 | ||
| 65QV | 30 | M | M | 23.4-111 | 6.5-30.8 | 5-29.5 | 700-1500 | 50 | 5 | 280 |
| 65QV | RU | RU | 22.5-105 | 6.25-29.15 | 5.5-30.5 | 700-1500 | 51 | 5 | 280 | |
| 100RV | 75 | M | M | 54-289 | 15-80.3 | 5-35 | 500-1200 | 56 | 5 | 370 |
| 100RV | RU | RU | 64.8-285 | 18-79.2 | 7.5-36 | 600-1200 | 62 | 5 | 370 | |
| 150SV | 110 | M | M | 108-479.16 | 30-133.1 | 8.5-40 | 500-1000 | 52 | 5 | 450 |
| 200SV | 110 | M | M | 189-891 | 152.5-247.5 | 6.5-37 | 400-850 | 64 | 5 | 520 |
| 250TV | 200 | M | M | 261-1089 | 72.5-302.5 | 7.5-33.5 | 400-750 | 60 | 5 | 575 |
| 300TV | 200 | M | M | 288-1267 | 80-352 | 6.5-33 | 350-700 | 50 | 5 | 610 |
SP/SPR noncorrosive submersible agitator slurry pump PUMP INTRODUCE
1. Wear-resistant metal, the impeller selection of wear-resistant metal or rubber, polyurethane material.
2. SVR type sump pump spare parts are immersed in liquid rubber lining.
3. Different length of the pump drive shaft or inhaled can be selected according to the residue slurry pond surface level,
4. These pumps have no need of any shaft seal and sealing water
5. Both more steady operation and wider application range, but flushing water should to the guide bearing
6. Bearing used lubricating oils.
7. Drive type: V-belt drive and flexible coupling.
8. The use of variable-speed and a variety of ways, making the best condition in the pump operation, long service life, run-effective and can meet many bad transportation conditions.
An Pump Machinery is your Best noncorrosive submersible agitator slurry pump Manufacturer
An Pump Machinery Co. ,Ltd is the pump manufacturer with 50+ years experienced
Our pumps export to over 90 countries all over the world in mining, power plant, dredging and dredge, hydraulic, irrigation, pulp transfer, chemical, construction, sea water and oil & gas transfer etc. click to more...
