Heavy duty centrifugal pump for mining Industry submersible sand dredging pump
- 1000 Piece / Pieces per Month
- xingang
- T/T L/C D/P D/A Credit Card PayPal
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Hebei, China | Brand Name: | AN PUMP | Model Number: | QSZ |
Theory: | Centrifugal Pump | Structure: | Single-stage Pump | Usage: | Other, Mining, power plant, Chemical plant, waste water plant |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, motor |
Pressure: | High Pressure | Application: | Other, Pumping mining slurry, solid particle solution, waste water |
Product Description
Heavy duty centrifugal pump for mining Industry submersible sand dredging pump
Description / submersible sand dredging pump
QSZ submersible slurry pump is our factory technical personnel absorbing foreign advanced technology and combined with the actual situation of the majority of users, the design research and development, motor and pump coaxial integrated directly into the medium to work hydraulic machinery. The product is excellent selection, advanced structure, wide flow channel through ability, metallurgy, chemical, mining, power plants and other enterprise for conveying containing sand, cinder, tailings and other natural particles or liquids, it is the ideal alternative of traditional slurry pump . The products add a mixing impeller in the bottom by another except main impeller and can precipitate in the slag jet hit the water and solid particles into the mixing liquid, the pump in the case where no auxiliary means to achieve a transport of high concentration. Unique sealing
device can effectively balance the pressure inside and outside of oil chamber, making mechanical seal both ends of the pressure to maintain a balance, the maximum guarantee reliable operation of the mechanical seal, greatly prolonging its life, the motor according to user requirements increase water testing, overheating and other protection devices that make products for harsh working conditions for long-term safe operation.
Application / submersible sand dredging pump
1. Pumping tailing slurry for industrial and mining organizations;
2. Sucking silt in sedimentation basin;
3. Pumping silty sand or fine sand for seashore or port;
4. Pumping powdery iron ore for foreign countries, etc;
5. Deliver a solid particles of mud, larger pulp, coal slurry, sandstone, and other media;
6. Sucking from all kinds of fly ash power plant, coal slime
Structure and operating principle / submersible sand dredging pump
QSZ type submersible slurry pump for the pump and motor coaxial , through the motor shaft driven pump impeller rotation when operation, the energy transfer to the slurry medium, thus producing a certain velocity, led solids flow to achieve slurry delivery.
Main features are as follows:
1. Machine is dry type motor pump structure. Motor adopt mechanical seal protection and can be
effectively prevent high-pressure water and contaminants into the motor cavity.
2. In addition to the main impeller, also equipped with mixing impeller and can be extracted residue
stirred into a turbulent precipitate at the bottom of the post .
3. Impeller, mixing impeller and other major wet parts using high wear-resistant material
manufacturing, wear-resistant , corrosion resistance, non-clogging blowdown ability , can be
through larger solid particles effectively .
4. No limitation by suction head , high efficiency suction slag , more thoroughly cleaning .
5. Without auxiliary vacuum pumps, investment cheaper.
6. No equipped with auxiliary mixing or spraying devices , operation more convenient .
7. Motor submerged, without building complex ground protection and fixtures, management more
convenient and easy.
8. Mixing impeller direct contact deposition surface, control concentration through dive depth ,
therefore concentration control more comfortable.
9. Device directly submerged to work, no noise and vibration, scene cleaner.
Performance chart / submersible sand dredging pump
Materials / submersible sand dredging pump
Easy Installation / submersible sand dredging pump
(1). Electrical wiring
(a) Pump power cables for the four cores, three power lines, a ground wire; pump equipped with a
protective device with corresponding control cables; pump cable cores have different functions
signage signs, see below table : In strict accordance with the identification card
cores indicated the same identity with the control cabinet wiring terminals. With a multimeter check
the ground wire core wire with the respective resistance values should be consistent with the
requirements of the table. Ground wire must be grounded.
(b) It should be always test insulation resistance during installation, detecting the motor insulation
resistance shall not be less than 5MΩ after descend the well ; Connect the electrical equipment will be
enabled.
(c) power-on , such as the pump less water , the pump may be connected in reverse, stop swap any
two connector of three-phase power cable .
(2). Install Way:
Installation for the mobile installation, the pump upright vertical suspended into the water, place
should be smooth; then fasten the cable, connect the pump outlet pipe; this method easy to install,
easy to move.
Cable description / submersible sand dredging pump
Operation condition / submersible sand dredging pump
1. Power supply 50Hz , 380V , 3-phase , ACpower .
2. The highest temperature of medium shall not exceed 40 ℃, the medium does not contain
flammable gases.
3. The maximum volume of concentration solid particles is 30% in medium and the maximum
medium density is 1.2kg / L.
4. The unit maximum diving depth does not exceed the 20 meters, the minimum diving depth
to drown motor prevail.
5. Unit in the medium with vertical to work for good , operating mode for continuous operation.
Note: When site conditions does not comply with above provisions, please note when ordering, can
be customized according to requirements .
You will own products advantage
*About 30 years Design, produce and service experience.
*Price is suitable. We are directly factory, own finished foundry model, cost only including original materials fee, machinery fee, worker fee.
*Quality, our materials used high chrome, reached above 27%, 28%, wear resistant and corrosion resistant , pump use life longer. High products quality, All our pump material is wear-resistant high Chrome alloy or nature rubber. All our products Pass ISO9001:2008 and CE certificate
*After sale service, we can offer 2 years quality guarantee, also have a very strong technical support department and special after sale service department. When you have any need future, we can sent you professional technical man to Russian help you. We also have one of group high quality technicians who can help you solve any question during the process
*When received your order, we have very professional manufacture process and supervision process. For you, i also will to plant supervise manufacture and take photo for you per day in person. So can keep you do not worry.
*After finish manufacture, we will test each pump. take a video and make a testing report for you. If available, you also can to our factory to supervise testing in person.
*Fast Delivery: For pump standard parts, we have large stock, so we can arrange delivery very soon
*Rich export Experience. we had export USA, Germany,Canada , Australian and so on developed country and South Africa, Southeast Asia,south America, North America, Russia and so on many country. our products get high reputation at home and abroad.
