High Efficiency Marble Transfer Slurry Pump

High Efficiency Marble Transfer Slurry Pump thumbnail-1
High Efficiency Marble Transfer Slurry Pump thumbnail-2
High Efficiency Marble Transfer Slurry Pump thumbnail-3
High Efficiency Marble Transfer Slurry Pump thumbnail-4
High Efficiency Marble Transfer Slurry Pump photo-1
High Efficiency Marble Transfer Slurry Pump photo-2
High Efficiency Marble Transfer Slurry Pump photo-3
High Efficiency Marble Transfer Slurry Pump photo-4
US$ 500 - 180,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
An Pump
Model Number:
AM/AMR marble transfer slurry pump
Contact Supplier Request Quote Chat Now
Shijiazhuang An Pump Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin shanghai shenzhen qingdao etc any port of China is ok
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name An Pump
Model Number AM/AMR marble transfer slurry pump
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Other, marble transfer slurry pump
Power Other, Electric, 15 - 560 kw
Standard or Nonstandard Standard
Fuel Other, marble transfer slurry pump
Pressure Other, standard
Application Other, slurry liquid, slage,sludge, sewage, solid liquid etc



Company Information

     Shijiazhuang An Pump Machinery Co.,Ltd is a manufacturer and trading enterprise, which is mainly engaged in pump

designing, manufacturing, selling and service. We develop the international trading business of mining equipment, slurry pumps, and water pumps according the wide customer resource, comprehensive technology and reasonable staffing.





       An pump machinery’s main products includes: slurry pump, desulfurization pump, gravel pump, mud pump, sewage

 pump, submersible pump, submersible sewage pump, impurity pump, large capacity split casing pump, high head

multistage water pump, end suction pump, self priming pump, pump parts and ancillary equipment). which can satisfy

different kinds of demands.





Product Description



 General information of slurry pump



      AM/AMR series is horizontal, cantilevered centrifugal slurry pump, with reasonable construction, reliable operation, long service life. It is widely used in transporting abrasive or / and corrosive slurry in mining, metallurgy, electric power, coal, chemicals, building, etc. Especially well accepted by coal / chrome washing plant, mineral processing plant, power plant etc.



 high efficiency marble transfer slurry pump



Design Features of slurry pump



• Bearing assembly – A large diameter shaft with short overhang minimizes deflection and contributes to long bearing life. Only four  through bolts are required to hold the cartridge type housing in the  frame.

• Liners – Easily replaceable liners are bolted, not glued, to the casing for positive attachment and ease of maintenance. Hard metal liners are completely interchangeable with pressure molded  elastomers. Elastomer seal rings back all liner joints.

• Casing – Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.

• Impeller – Front and rear shrouds have pump out vanes that reduce recirculation and seal contamination. Hard metal and molded elastomer impellers are completely interchangeable. Cast  in impeller threads require no inserts or nuts. High efficiency and high head designs are also available.

• Throat bush – Wear is reduced and maintenance simplified by the use of tapered mating faces to allow positive accurate alignment during assembly and simple removal.

• One-piece frame – A very robust one-piece frame cradles the cartridge type bearing and shaft assembly. An external impeller adjustment mechanism is provided below the bearing housing for

easy adjustment of impeller clearance.



AM/AMR slurry pump structure





high efficiency marble transfer slurry pump



Metal liner

Rubber liner

1

Volute liner

1

Frame plate

2

Frame plate

2

Expeller ring

3

Frame plate liner insert

3

Gland assembly

4

Cover plate

4

Shaft sleeve

5

Throat bush

5

Expeller

6

Impeller

6

Frame plate liner

7

Expeller ring

7

Impeller

8

Shaft sleeve

8

Cover plate liner

9

Expeller

9

Cover plate

10

Bearing assembly

Note: Slurry pumps have Throat Bush from 4"







AM,AMR slurry pump performance data





Model

Max Power

(kw)

Material

Clear water performance

Liner

Impeller

Capacity Q

(m3/h)

Head

H ( m)

Speed

n (rpm)

1.5/1B-AM

15

M

M

12.6~28.8

6~68

1200~3800

RU

RU

10.8~25.2

7~52

1400~3400

1.5/1B-AMH

30

M

M

16.2~34.2

25~92

1400~2200

2/1.5B-AM

15

M

M

32.4~72

6~58

1200~3200

RU

RU

25.2~54

5.5~41

1000~2600

3/2C-AM

30

M

M

39.6~86.4

12~64

1300~2700

RU

RU

36~75.6

13~39

1300~2100

4/3C-AM

30

M

M

86.4~198

9~52

1000~2200

4/3D-AM

60

4/3C-AM

30

RU

RU

79.2~180

5~34.5

800~1800

4/3D-AM

60

4/3E-AMH

120

M

M

126~252

12~97

600~1400

6/4D-AM

60

M

M

162~360

12~56

800~1550

6/4E-AM

120

6/4D-AM

60

RU

RU

144~324

12~45

800~1350

6/4E-AM

120

6/4F-AMH

260

M

M

100~414

34~98

600~1000

8/6E-AM

120

M

M

360~828

10~61

500~1140

8/6E-AM

120

RU

RU

324~720

7~49

400~1000

10/8ST-AM

560

M

M

612~1368

11~61

400~850

RU

RU

540~1188

12~50

400~750

10/8E-MM

120

M

M

666~1440

14~60

600~1100

10/8E-MM

120

RU

RU

540~1188

10~42

500~900

12/10ST-AM

560

M

M

936~1980

7~68

300~800

M

M

720~1620

7~45

300~650

14/12ST-AM

560

M

M

1260~2772

13~63

300~600

RU

RU

1152~2520

13~44

300~500

16/14ST-AM

560

M

M

1368~3060

11~63

250~550

16/14TU-AM

1200

18/16ST-AM

560

M

M

2160~5040

8~66

200~500

18/16TU-AM

1200

20/18TU-AM

1200

M

M

2520~5400

13~57

200~400



AM, AMR Slurry Pump Performance Curve



high efficiency marble transfer slurry pump



Pump Application



slurry pump Applications



Chemical Process

Heavy Minerals

Paper and Pulp

Mill Discharge

Sugar Beet

Slag Granulation

Bottom Boiler and Fly Ash

Cyclone Feed

Power Utilities



Packaging & Shipping





 high efficiency marble transfer slurry pump

 high efficiency marble transfer slurry pump





Our Services

An Pump Machinery Company to Customers:



1)Quality first. We guaranteed every part of the pump must be inspected closely

2)We can help you select suitable pump model according to your working condition and requirements.

3)We can design the related base or engine for your pumps.

4)Fast delivery time, large quantity of spare parts in stock.

high efficiency marble transfer slurry pump
