Factory supply axial split case sea water pump
Factory supply axial split case sea water pump feature
Caliber |
DN80-800mm |
Capacity |
Q≤11600m³/h |
Head |
H≤200m |
Working pressure |
P≤2.5Pa |
Working temperature |
T≤105°C |
Working voltage |
U=380V,6KV,10KV |
A. Compact structure, space effective and much shorter axial dimensions.
B. Small vibration and low noise, achieved mainly by means of the follow:
1) The pump casing adopts the double-volute structure
2)The rotor part has short axial dimensions and a good rigidity.
3)The pump shaft adopts the imported high-precision bearing for the support.
Factory supply axial split case sea water pump description
Type QS,QSH pumps are single stage, double suction with horizontally split casings.
Type QS ,QSH pumps are adoptable in factories, mines, water works, power stations, hydraulic engineering, irrigation or drainage services in agriculture, etc.
Factory supply axial split case sea water pump advantage
1. Bearing spacing between both ends is short, pump running stable, low vibration noise, and can increases the speed of running properly, to adapt to a wider range of performance.
2. Inlet and outlet at the same line, so that the pipeline layout is simple and convenient, beautiful.
3. The rotation of the same rotor can be reversed, reducing the risk of damage caused by the water hammer.
4. Unique design of high temperature, use of intermediate support, thick body, sealed cooling, bearing lubrication, so that the pump can run up to 200 ºC occasions, especially for heating network requirements.
5. Pump can be vertical or horizontal installed according to using conditions, seal can be mechanical seal or packing seal.
Factory supply axial split case sea water pump parameter
Model |
Flow rate |
Head |
Speed |
Power |
Eff |
Iimpeller |
Weight |
(QS) |
(m3/h) |
(m) |
(rpm) |
(KW) |
(%) |
(mm) |
(kg) |
QS150 |
110~220 |
35~84 |
2900 |
30~55 |
67~80 |
186~250 |
145~150 |
QS200 |
160~351 |
31~100 |
2900 |
37~110 |
61~85 |
193~284 |
219~265 |
QS250 |
324~612 |
8.6~71 |
1450 |
22~132 |
72~86 |
224~460 |
405~565 |
QS300 |
504~972 |
8~98 |
1450 |
30~300 |
70~84 |
225~540 |
845~660 |
QS350 |
745~1663 |
10~140 |
1450 |
55~680 |
70~88 |
270~655 |
760~1580 |
QS400 |
900~1620 |
32~98 |
980~1480 |
155~500 |
71.5~84 |
510~535 |
1910 |
QS500 |
1150~2450 |
10.6~108 |
740~970 |
110~800 |
70~89 |
390~860 |
2000~4330 |
QS600 |
2304~4000 |
13~80 |
730~970 |
185~900 |
70~91 |
450~830 |
2500~4300 |
QS700 |
2111~4896 |
39.5~99.5 |
740~980 |
560~1250 |
52~92 |
415~850 |
5800 |
QS800 |
3960~7200 |
23.5~84 |
600~740 |
450~1600 |
77~92 |
715~990 |
5100~8300 |
QS1000 |
6000~9900 |
32~52 |
600~990 |
1250 |
79~87 |
670~695 |
10000 |
QS1200 |
5832~14400 |
6~95.7 |
500~745 |
710~3450 |
80~90 |
560~1200 |
12500~16000 |
Factory supply axial split case sea water pump curve
Factory supply axial split case sea water pump application
Factory supply axial split case sea water pump packing
Our Services
1. Offer Large capacity sea water pump solutions
2. Selection
3. OEM available
4. ODM available
5. Design
6. Installation
7. Maintenance
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An Pump Machinery company has its own Kingda type selection & design, research and development team, assure to provide you efficient, energy saving slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps type design, use and maintenance program.
Strong , experienced technical personnel is the powerful guarantee for quality products of slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps. An Pump Machinery technical team set up five R & D teams: hydraulic engineering, water pump structure, new materials research and development, casting, molding etc. Except the commonly used CAD and other design software, the technical teams also use CAPP computer-aided industrial design and CFD hydraulic design software. They combine years of experience in the practical application of the products, repeated use of water conservancy GIS, MIS software and simulation analysis system software demonstrated, calculations, the theoretical calculations product of slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps are accurate and consistent with the actual performance. It allowing users to meet the needs while significantly reducing the investment costs, improves An Pump Machinery Company's strong core competitiveness.
Learn more , please contact us directly.
