series horizontal split case sea water pump
series horizontal split case sea water pump feature
Caliber |
DN80-800mm |
Capacity |
Q≤11600m³/h |
Head |
H≤200m |
Working pressure |
P≤2.5Pa |
Working temperature |
T≤105°C |
Working voltage |
U=380V,6KV,10KV |
A. Compact structure, space effective and much shorter axial dimensions.
B. Small vibration and low noise, achieved mainly by means of the follow:
1) The pump casing adopts the double-volute structure
2)The rotor part has short axial dimensions and a good rigidity.
3)The pump shaft adopts the imported high-precision bearing for the support.
series horizontal split case sea water pump description
Type QS,QSH pumps are single stage, double suction with horizontally split casings.
Type QS ,QSH pumps are adoptable in factories, mines, water works, power stations, hydraulic engineering, irrigation or drainage services in agriculture, etc.
series horizontal split case sea water pump structure
series horizontal split case sea water pump parameter
Model |
Flow rate |
Head |
Speed |
Power |
Eff |
Iimpeller |
Weight |
(QS) |
(m3/h) |
(m) |
(rpm) |
(KW) |
(%) |
(mm) |
(kg) |
QS150 |
110~220 |
35~84 |
2900 |
30~55 |
67~80 |
186~250 |
145~150 |
QS200 |
160~351 |
31~100 |
2900 |
37~110 |
61~85 |
193~284 |
219~265 |
QS250 |
324~612 |
8.6~71 |
1450 |
22~132 |
72~86 |
224~460 |
405~565 |
QS300 |
504~972 |
8~98 |
1450 |
30~300 |
70~84 |
225~540 |
845~660 |
QS350 |
745~1663 |
10~140 |
1450 |
55~680 |
70~88 |
270~655 |
760~1580 |
QS400 |
900~1620 |
32~98 |
980~1480 |
155~500 |
71.5~84 |
510~535 |
1910 |
QS500 |
1150~2450 |
10.6~108 |
740~970 |
110~800 |
70~89 |
390~860 |
2000~4330 |
QS600 |
2304~4000 |
13~80 |
730~970 |
185~900 |
70~91 |
450~830 |
2500~4300 |
QS700 |
2111~4896 |
39.5~99.5 |
740~980 |
560~1250 |
52~92 |
415~850 |
5800 |
QS800 |
3960~7200 |
23.5~84 |
600~740 |
450~1600 |
77~92 |
715~990 |
5100~8300 |
QS1000 |
6000~9900 |
32~52 |
600~990 |
1250 |
79~87 |
670~695 |
10000 |
QS1200 |
5832~14400 |
6~95.7 |
500~745 |
710~3450 |
80~90 |
560~1200 |
12500~16000 |
series horizontal split case sea water pump curve
series horizontal split case sea water pump application
series horizontal split case sea water pump application
1. Q: Are you a trading company or manufacture?
A: An Pump Machinery Co., Ltd is a real large professional manufacturer more than 32 years, in China,
produce with our own factory.
2. Q: what's your factory workshops ?
A: My factoryproduce include casting, mechanical process, lathe process, heat treatment, assembly, and test etc.
Warmly welcome to visit & test my factory any time.
3. Q: How about your pump price?
A: We are sure our price is factory price, and insist high quality for our long term cooperation.
4. Q: What is your pump material ?
A: We produce high Cr Mo Ni alloy, rubber liner, cast iron, stainless steel, etc.
Produce as your requirements is ok.
5. Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end.
Our factory has 15~30 QC.
6. Q: Is it easy for customers to change the parts by myself ?
A: yes, the structure is simple,customers can change it very easily. We will also supply you maintenance tools for free.
7. Q: How to do if the pump or parts have operation problem within your warranty?
A: Tell me details timely, and show me pictures, we will send you solution at once without any hesistation.
8. Q: Can you install the motor or diesel engine with the pump for us ?
A: yes, we can, it's no problem, we are experienced in this .
