Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > 24" Sand and Gravel Pump

24" Sand and Gravel Pump

Name: 24" Sand and Gravel Pump
Brand: An Pump
SKU: 141180968
Availability: InStock

US$ 200 - 6,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

An Pump

Model Number:

AMG gravel pump,dredge pump,dredger pump

Contact Supplier Request Quote Chat Now

Shijiazhuang An Pump Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang/Shanghai/Guangzhou/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name An Pump

Model Number AMG gravel pump,dredge pump,dredger pump

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Other, sand and gravel pump,sand suction pump

Power Other, electric pump,siemens pump,

Standard or Nonstandard Other, standard,dredging pump,dredge pump,sand suction pump

Fuel Other, electric or diesel,dredger pump,sand dredging pump

Pressure Other, high pressure,sand pump,dredge pump

Application Other, sewage,sand,dredge,sand pump,gravel pump

24" sand and gravel pump

Product Description

24" sand and gravel pump introduction

1. Horizontal cantilevered single-casing centrifugal gravel pump.
2. Pump discharge direction in any of 360. Easy installation.
3. Cylinder bearing assembly, oil lubrication, adjusting the distance between impeller and pump,
4. Mechanical seal, expeller seal and packing seal
5. Wide passage, good performance of NPSH, anti-wearing and anti-corrosion, high efficiency
6. V belt driver, gearbox driver, elastic coupling driver, fluid couplings driver, frequency conversion driver, silicon controlled rectifier speed regulation etc.

24" sand and gravel pump parameter

Model	Outlet Dia (mm)	Speed (rpm)	Flow (m3/h)	Head (m)	Max Power (kw)	Max Solid (mm)
6/4D-AMG	100	600-1400	36-250	7-56	60	82
8/6E-AMG	150	800-1400	180-540	12-52	120	120
10/8F-AMG	200	500-1000	180-820	12-56	560	178
12/10G-AMG	250	400-850	360-1200	12-60	600	220
14/12G-AMG	300	300-700	700-2700	8-70	600	241
14/12TU-AMG	300	300-700	700-2700	8-70	1200	241
10/8F-AMGH	200	500-1100	50-900	20-90	560	180
12/10G-AMGH	250	350-700	500-2000	20-80	600	210
16/14TU-AMGH	350	250-500	1000-2800	20-80	1200	230

24" sand and gravel pump curve

24" sand and gravel pump structure

1.Shaft	2.Frame plate	3.Impeller stripping ring	4.Shaft spacer	5.Sealing assembly
6.Bowl	7.Frame plate liner insert	8. Pump casing	9.Adapter plate clamp ring	10.Pump cover
11.Throat bush		12.Impeller		13.Flange

24" sand and gravel pump benefit

a. Wear parts

The impeller and liner could be removed easily. The impeller and volute made of      high chrome alloy, which has good performance in wear-resisting.

b. Shaft sealing

Packing seal, expeller seal, mechanical seal

c. Bearing assembly

The bearing assembly is with large diameter shaft and short overhang minimizes deflection and vibration. Heavy duty roller bearings are adopted with Lithium white Grease and housed in a removable bearing cartridge. No leakage, a little maintenance, convenient rotor adjustment.
