Horizontal Stainless Steel Chemical Process Centrifugal Water Pump

Horizontal Stainless Steel Chemical Process Centrifugal Water Pump thumbnail-1
Horizontal Stainless Steel Chemical Process Centrifugal Water Pump photo-1
US$ 500 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
An Pump
Model Number:
Stainless Steel Pump
Contact Supplier Request Quote Chat Now
Shijiazhuang An Pump Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Tianjin any part of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name An Pump
Model Number Stainless Steel Pump
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Other, open impeller centrifugal chemical pump
Power Electric
Standard or Nonstandard Standard
Fuel Diesel
Pressure High Pressure
Application Other, hydrochloric acid pump, Chemical, Delivering Corrosive Liquid.

                              Horizontal Stainless Steel Chemical Process Centrifugal Water Pump

Horizontal Stainless Steel Chemical Process Centrifugal Water Pump

Stainless steel pump introduction:
stainless chemical pump is kind of energy-saving pump, developed by us after studying relevant technical data both domestic and abroad, and also making much improvement. The SZ series self-priming centrifugal pump, featured by a compacted structure, easy and stable operation, easy maintenance, high efficiency, long life, strong self-priming capacity etc.

Stainless steel pump feature:
1. Horizontal cantilevered single-casing centrifugal  pump.
2. Pump discharge direction in any of 360. Easy installation.
3. Cylinder bearing assembly, oil lubrication, adjusting the distance between impeller and pump,
4. Mechanical seal, expeller seal and packing seal
5. Wide passage, good performance of NPSH, anti-wearing and anti-corrosion, high efficiency
6. V belt driver, gearbox driver, elastic coupling driver, fluid couplings driver, frequency conversion driver, silicon controlled rectifier speed regulation etc.

Applications:
Pure water feed or transfer
Chemical feed or transfer
Pharmaceutical services
Food or beverage services, not requiring FDA rating
Condensate return
Water reclamation and treatment
Stainless steel pump structure
Horizontal Stainless Steel Chemical Process Centrifugal Water Pump
1Pump casing4Impeller nut7Mid bracket
2Impeller5Pump cover8Shaft
3Seal ring6Seal part9Hanging stand
Stainless steel pump performance Curve Chart
Horizontal Stainless Steel Chemical Process Centrifugal Water Pump
Stainless steel pump performance:
Pump TypeCapacity (m3/h)Head (m)Speed (rpm)Motor Power(kw)Eff (%)
QI 503-143.7-821450-29000.55-1121.5-60
QI 656-303.8-115.41450-29000.55-3025-75
QI 8012-603.6-1281450-29000.55-3739-75
QI 10024.3-1203.7-1331450-29001.1-7551-78
QI 12551.4-2408.4-1331450-29004-11052-81
QI 150104-24013-53145011-4562-81
QI 200194-46013.1-55145022-9065.5-82
QI 250320-76022.6-52148075-13267.5-84.5
QI 300530-120021.9-38148090-13261.66-107.6
