6 Inch Farm Irrigation Movable Diesel Water Pump

6 Inch Farm Irrigation Movable Diesel Water Pump thumbnail-1
6 Inch Farm Irrigation Movable Diesel Water Pump thumbnail-2
6 Inch Farm Irrigation Movable Diesel Water Pump photo-1
6 Inch Farm Irrigation Movable Diesel Water Pump photo-2
US$ 100 - 1,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
An Pump
Model Number:
QI Centrifugal portable suction pump
Contact Supplier Request Quote Chat Now
Shijiazhuang An Pump Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name An Pump
Model Number QI Centrifugal portable suction pump
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Water
Power Electric
Standard or Nonstandard Standard
Fuel Diesel
Pressure Other, standard
Application Other, Centrifugal portable suction pump

6 Inch Farm Irrigation Movable Diesel Water Pump



 6 inch farm irrigation movable diesel water pump

Description: QS, QSH series pump one of the main characters is large flow rate. It can reach 110m3/h-10000m3/h. The pump structure simple, easy for operation and maintenance. It is suitable for pure water or liquids similar to water in physico-chemical property. We can use stainless steel material for the corrosion liquids. This model is widely used in agriculture irrigation, fire fighting, steel, power industry. The pump head range 6-145m, it can be used in series when high head. Small amount of particles <10mm can pass through.

1) Easy installation and move, open back structure makes it easy to take out the rotor;

2) Pump body support by anchor assure the stable structure and maximum resistance off-center and distortion caused by line load;

3) No overload design, make sure performance operate stably;

4) Adopt national standard hydraulic model make sure high operation efficiency and good anti-cavitation performance;

5) Packing seal and mechanical seal are available.

What is the  Farm Irrigation Movable Diesel Water Pump Performance ?

Type

Capacity

(m3/h)

Head

(m)

Speed

(r/min)

Power

(Nm)

Efficiency

η(%)

QS150

112-220

35-84

2900

30-55

68-80

QS200

160-351

31-100

2900

37-110

61-85

QS250

324-612

8.6-65.1

1450

22-132

72-86

QS300

504-1663

8.7-140

1450-1470

22-680

70-87

QS350

745-1570

10-125

1450-1470

55-630

70-88

QS400

900-1620

32-85.5

980-1480

440-500

71.5-84

QS500

1150-3800

10.6-108

740-970

110-800

70-89

QS600

2300-4000

13-80

730-970

145-730

70-91

QS700

2111-4896

39.5-99.5

742-980

397-1252

52-92

QS800

3960-688

23-84

600-750

450-1600

77-92

QS1000

6600-9900

32-52

600

1250

79-88

QS1200

5832-14400

6-95.7

500-745

710-3450

80-90



 Detail performance and technical information please send email below for more!

What is the  Farm Irrigation Movable Diesel Water Pump Applications?

  • Agriculture water supply
  • Agriculture irrigation water feed
  • Circulating Water Systems
  • Fire Fighting
  • Irrigation
  • Paper Mills
  • Pharmaceuticals
  • Ports & Docks
  • Sugar Mills
  • Vegetable Oil Mills
  • Water / Effluent Treatment
  • Sea/river Water delivery

 Farm Irrigation Movable Diesel Water Pump shows







Our Services

An Pump Machinery Company to Customers:



1)Quality first. We guaranteed every part of the pump must be inspected closely

2)We can help you select suitable pump model according to your working condition and requirements.

3)We can design the related base or engine for your pumps.

4)Fast delivery time, large quantity of spare parts in stock.
