12 Inch Self-priming Diesel Water Pump
>>>Specification of 12 inch self-priming diesel water pump
| Model |
Rotation Speed |
Capacity | Head | Shaft Power |
Inlet and Outlet Dia. |
Max. Passing Solid Dia. |
Max. Suction Lift |
|
| rpm | m3/h | m | KW | HP | mm | mm | m | |
| JT-12 | 750 | 600 | 10 | 22 | 30 |
300 (12inch) |
65 | 2.7 |
| 850 | 700 | 12.5 | 30 | 41 | 3.9 | |||
| 950 | 800 | 18 | 55 | 75 | 4.5 | |||
| 1050 | 900 | 17 | 75 | 102 | 4.9 | |||
| 1150 | 1100 | 18.5 | 90 | 122 | 4.9 | |||
| 1250 | 1200 | 21 | 110 | 150 | 4.9 | |||
| 1450 | 1350 | 23 | 160 | 217 | 4.9 | |||
| Model |
Rotation Speed (rpm) |
Flow Rate (m3/h) |
300 | 400 | 560 | 800 | 900 | 1100 | 1350 |
| JT-12 | 750 |
Head (m) |
14.0 | 13 | 12.0 | 7.0 | |||
| 850 | 18.0 | 17.5 | 16.0 | 11.0 | 7 | ||||
| 950 | 23.5 | 23.0 | 21.0 | 18.0 | 15.0 | ||||
| 1050 | 28.0 | 27.0 | 26.0 | 21.0 | 18.0 | 12.5 | |||
| 1150 | 35.0 | 34.0 | 32.0 | 26.0 | 24.0 | 18.5 | |||
| 1250 | 42.0 | 38.0 | 36.0 | 31.0 | 25.0 | ||||
| 1450 | 45.0 | 42.0 | 39.0 | 32.0 | 23.0 |
>>>Introduction of JT&JU series self priming centrifugal pump
JT&JU series self priming centrifugal pump is a kind of specialized sewage disposal equipment, designed with super strong anti-clogging and impurity disposal capability. It can be used to dispose ultra long fiber impurities and more than 3 inch solids. In addition, because of it's self priming function and high suction lift performance, our water pump can transfer water from river or well. Therefore, This pump can be used as agriculture irrigation pump, dewatering pump, fire fighting pump and other pump.
>>>Specification of JT&JU series self priming centrifugal pump
| Model | JT/JU series non clog self-priming centrifugal sewage pump |
| Structure | horizontal, single stage, single suction, self priming |
| Size | 2 inch, 3 inch, 4 inch, 6 inch, 8 inch, 10 inch, 12 inch |
| Max. Flow | 1350 m3/h |
| Max. Head | 63 m |
| Max. Suction Lift | 7.6 m |
| Rotation Speed | 76 mm |
| Max. Passing Solids | 650-3200 rpm |
| Shaft Seal | Mechanical Seal |
| Pump Material | Cast Iron, Stainless Steel 304/316/316L |
| Impeller Material | Cast Iron. Stainless Steel 304/316/316L |
>>>Parameter Table
| Model | Size |
Max. Flow |
Max. Head |
Max. Suction Lift |
Power |
Rotation Speed |
Max. Passing Solids |
| (inch) | (m3/h) | (m) | (m) | (hp) | (r/min) | (mm) | |
| JT-2 | 2 | 45 | 36 | 7.6 | 1.5-15 | 1250-3200 | 44.45 |
| JT-3 | 3 | 100 | 34 | 7.6 | 2-25 | 750-2350 | 63.5 |
| JT-4 | 4 | 160 | 35 | 7.6 | 2-35 | 750-2150 | 76 |
| JT-6 | 6 | 315 | 31 | 7.6 | 5-50 | 750-1750 | 76 |
| JT-8 | 8 | 550 | 33.5 | 7 | 10-85 | 650-1450 | 76 |
| JT-10 | 10 | 750 | 38 | 6.7 | 20-120 | 650-1600 | 76 |
| JT-12 | 12 | 1350 | 45 | 4.9 | 20-125 | 750-1450 | 65 |
| JU-3 | 3 | 80 | 63 | 7.6 | 2-30 | 1050-2350 | 20.63 |
| JU-4 | 4 | 140 | 60 | 5.2 | 5-50 | 1150-2350 | 28.57 |
| JU-6 | 6 | 300 | 58 | 4.5 | 7.5-90 | 1150-2150 | 31.75 |
1) Outstanding Self Priming Performance
Ultra strong self priming performance enables this pump to be installed above the liquid level. Long drive shaft, hanging bracket and other devices are not required. What it only requires is to pump suction pipe into sewage. In first use, you only need to fill up the pump chamber with liquid to complete initial self priming. Then, the sewage pump can automatically conduct self priming, thus dramatically reducing installation time and maintenance cost.
2) Nearly Zero Clogging
Semi-open impeller design allows relatively large size solids and super long fibers to pass through the waster water pump. The maximum diameter of solid particles is up to 3 inch. Even if it is clogged, the manual discharge port installed at the front of the pump can be easily opened to clear up the pump in few minutes.
3) Simple, Quick and Economical Maintenance
If you want to inspect or change impeller, mechanical seal, wear plate or other parts, the only thing you need to do is to open the front cover and take out the rotating assembly without having to dismantle the pipeline or pump.
More Product, you can visit our online shop.
1. Delivery: Delivery time will be on time as the contract. Usually, the delivery time of pump is 10-15 working days.
2. Warranty: 1 year for the pump body, 3months for the main working parts.
3. Package: According to your quantity, we use strong carton or plywood case which is durable for ocean transport.
4. Shipping: By Sea or By Air.
5. Payment: we can accept T/T, L/C, West Union and so on.
6. Pre-sales Service: According to your requirement, we will give you our profession advice of pump solution.
7. On-sales Service: We will clearly show you everything in fact when you place an order with us. We will takes photos or videos to show you our production situation.
8. After-sales Service: We will full report you the production progress and plan. Meanwhile, we will follow up the pump working conditions per three months when the pumps put into use, and can send the spare parts to you within one week if u need.
