2 inch electric motor driven acid pump
- 500 Unit / Units per Month
- Shanghai or Ningbo
- T/T L/C D/P D/A Credit Card PayPal
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Shanghai, China | Brand Name: | Y&L | Model Number: | DAZ |
Theory: | Centrifugal Pump | Structure: | Single-stage Pump | Usage: | Water |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, Electric |
Pressure: | High Pressure | Application: | Other, Acid Transfer |
Product Description
2 inch electric motor driven acid pump
>>>Parameter Range
The Specification of DAZ Series Centrifugal Pump | |
Flow Rate | 2-700 m3/h |
Head(H) | 2-152m |
Speed | 1450~2900 rpm (50HZ), 1750~3500 rpm (60HZ) |
Temperature | -10 Celsius to 105 Celsius |
Working Pressure | 1.2 MPa standard, 1.6 MPa standard on request |
>>> Material Table of Pump Parts
Pump Parts | Material |
Casing | Cast Iron standard, Ductile Iron, Stainless Steel optional |
Impeller | Bronze standard,Cast Iron,Stainless Steel optional |
Shaft | ASTM420standard, ASTM304, ASTM316, ASTM1045 optional |
Shaft Seal | Mechanical Seal (Carbon-Sic/Viton) |
>>> Parameter Table of 2 inch electric motor driven acid pump
Model | Capacity | Head | Rotation Speed | Shaft Power | Motor Power | Efficiency | Impeller. Dia | NPSH(r) |
m3/h | m | r/min | kw | kw | % | mm | m | |
DAZ50/13-01104 | 17.4 | 6.8 | 1450 | 0.54 | 0.75 | 59 | 139 | 2.2 |
28.9 | 6.3 | 0.69 | 1.1 | 72 | 2.4 | |||
34.7 | 5.8 | 0.75 | 1.1 | 73 | 2.7 | |||
DAZ50/13-00754 | 16.2 | 5.8 | 1450 | 0.44 | 0.75 | 58.5 | 130 | 2.2 |
27.1 | 5.2 | 0.53 | 0.75 | 72 | 2.4 | |||
32.5 | 4.7 | 0.58 | 0.75 | 72 | 2.7 | |||
DAZ50/13-00554 | 15.0 | 4.9 | 1450 | 0.33 | 0.55 | 62 | 120 | 2.2 |
25.0 | 4.4 | 0.42 | 0.55 | 71 | 2.4 | |||
30.0 | 3.8 | 0.45 | 0.55 | 69 | 2.7 | |||
DAZ50/13-00554 | 13.7 | 4.1 | 1450 | 0.25 | 0.55 | 61 | 110 | 2.2 |
22.9 | 3.4 | 0.32 | 0.55 | 67 | 2.4 | |||
27.5 | 2.8 | 0.33 | 0.55 | 64 | 2.7 | |||
DAZ50/16-01504 | 18.5 | 10.5 | 1450 | 0.81 | 1.1 | 65 | 174 | 2.1 |
30.9 | 9.5 | 1.08 | 1.5 | 74 | 2.2 | |||
37.1 | 8.8 | 1.27 | 1.5 | 70 | 2.4 | |||
DAZ50/16-01504 | 17.6 | 9.4 | 1450 | 0.71 | 1.1 | 64 | 165 | 2.1 |
29.3 | 8.5 | 0.93 | 1.5 | 73 | 2.2 | |||
35.1 | 7.8 | 1.02 | 1.5 | 73 | 2.4 |
More Model, please contact me.
Application
- Heating, ventilation and air-conditioning
- Fire Protection and Fire Fighting
- Water circulation
- Liquid transfer
- Irrigation
- Cooling
- Booster service
(If you are confused about whether our pump are suitable, please contact me for confirmation)
1) Running smoothly: The absolute concentricity of the pump shaft the excellent static and dynamic balance ability of the impeller ensure the smooth operation of the pump.
2) Low noise: Two low-noise bearings support the water pump, running smoothly, and there is no noise except the weak noise of the motor.
3) High efficiency: simple structure and using high quality pump parts.
4) Easy maintenance. It is easy to replace the seal , bearing and some others.
5) Small footprint: the outlet of the pump can be to the left, right and up three direction, which is convenient to installation and save space.
DA Series End Suction Centrifugal Pump (Long Coupling)
ISO Series End Suction Centrifugal Pump (Meet the stadard of ISO2858)
1. Delivery: Delivery time will be on time as the contract. Usually, the delivery time of pump is 7-15 working days.
2. Warranty: 1 year for the pump body, 3months for the main working parts.
3. Package: According to your quantity, we use strong carton or plywood case which is durable for ocean transport.
4. Shipping: By Sea or By Air.
5. Payment: we can accept T/T, L/C, West Union and so on.
6. Pre-sales Service: According to your requirement, we will give you our profession advice of pump solution.
7. On-sales Service: We will clearly show you everything in fact when you place an order with us. We will takes photos or videos to show you our production situation.
8. After-sales Service: We will full report you the production progress and plan. Meanwhile, we will follow up the pump working conditions per three months when the pumps put into use, and can send the spare parts to you within one week if u need.
Contact Person: Devin Chen
Whatsapp: +86 13968717283
Wechat: 1124650298
Email: devin@
or you can directly send me inquiry with your requirement.
