Specifications
Hydraulic Punching Machinery/hydraulic veneer press line/pipe/holes1.efficient
2.well equipped
Hydraulic Punching Machinery/hydraulic veneer press line/pipe/holes
1. MAIN TECHNICAL PARAMETER
Model | BC-10T |
Power | 1.5Kw |
Table Size | 310x360 |
Weight | 620kg |
Pressure | 10t |
Overall dimensions(mm) | 820x680x1500 |
Max,Wash of Cutting Dint | 110kn |
Swing Beam Width(mm) | 200 |
Stroking Regulate Range(mm) | 5-75 |
Wash of Cutting Speed | 0.10m/s |
Up and Down Operation Bed Distanc for Usage | 30-90mm |
Down Table Size(mm) | 680x410 |
Electric of Power | 1.5Kw |
2. DETAILED PRODUCT DESCRIPTION
2.1. This bag punching machine is suitable for punching, Vest-bag and shopping bag. Hydraulic punching. Economic and high quality.
2.2. Hydraulic pressure cutting and punching machine/bag making machine.
2.3. This Machine use mould to make T-shirt bag or hole in the flat bag.
2.4. It is a hydraulic pressure machine, can work very silent, and have strong power about 8-10 tons. So can used for making large bags.
2.5. It is a machine working with LDF Series Bag Making Machines.
3.PICTURES
